Schneider Electric ZB4FA18 industrial pushbutton head
The ZB4FA18 is a white flush-mounting illuminated pushbutton head designed for easy legend insertion, featuring a round shape, built-in-flush head, and spring return operator profile. It has a mounting diameter of 30.5 mm, overall dimensions of 36.6 mm in width and height, and depth of 31 mm. Its construction includes chromium-plated metal bezel, providing IP66, IP67, IP69/IP69K protection, withstanding up to 10 million cycles of mechanical durability. It is suitable for industrial automation with LED illumination options and complies with IEC, UL, CSA, and other standards.
Schneider Electric ZB4FA18 industrial pushbutton head Specifications:
- Bezel material: Chromium plated metal
- Mounting diameter: 30.5 mm (1.20 in)
- Overall width: 36.6 mm (1.44 in)
- Overall height: 36.6 mm (1.44 in)
- Overall depth: 31 mm (1.22 in)
- Net weight: 0.06 kg (0.13 lb)
- Mechanical durability: 10,000,000 cycles
- IP protection: IP66, IP67, IP69/IP69K
- Vibration resistance: 5 gn 10-500 Hz
- Shock resistance: 30 gn for 18 ms
- Standards: IEC 60947-5-1, UL 508, CSA C22.2, CE
- Ambient temperature (operation/storage): -40°C to +70°C
- Protection class: Class IEC 60536, IK06
- Certifications: UL Listed, CSA, CCC, EAC
Buy the Schneider Electric Series Harmony XB4 Pushbutton: ZB4FA18
Enhance your control panel with the ZB4FA18 white flush-mount illuminated pushbutton head, designed for legend insertion and durable operation. Featuring a round shape and chrome bezel, it offers IP69/IP66 protection, ensuring reliable performance in harsh industrial environments. Its high mechanical durability of 10 million cycles makes it ideal for demanding applications. Compatible with LED illumination options, this pushbutton meets IEC, UL, and CSA standards, providing safe, robust, and efficient control solutions for automation systems.
Get Schneider Electric ZB4FA18 today—built for durability and reliable industrial control.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA18?
You can click on the BUY or RFQ button to purchase ZB4FA18 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA18?
You can download the ZB4FA18 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA18?
Schneider Electric
