Schneider Electric ZB4FA2 Industrial Push Button
This compact industrial push button head features a sturdy metal construction with a sleek black finish, designed for flush mounting. It is suitable for diverse control applications, offering high durability with 10 million cycles. The round head measures 1.44 inches in width and height with a mounting diameter of 1.20 inches (30.5 mm). It conforms to IP66/IP67/IP69K protection standards, making it resistant to dust, water, and harsh environments. Certified by UL, CSA, and other standards, it is an ideal choice for reliable, industrial-grade emergency stop and control stations, ensuring long-lasting performance in demanding conditions.
Schneider Electric ZB4FA2 Industrial Push Button Specifications:
- Shape of signaling unit: Round
- Head type: Built-in-flush
- Material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Mechanical durability: 10,000,000 cycles
- Protection rating: IP66, IP67, IP69K
- Temperature range for operation and storage: -40°F to 158°F (-40°C to 70°C)
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA C22.2 No 14
- Vibration resistance: 5 gn 10-500 Hz
- Shock resistance: 30 gn (18 ms)
- Certification: UL Listed, CSA, EAC
- Package weight: 1 lb (0.45 kg)
- Package dimensions: height 1.73 in, width 2.05 in, length 2.47 in
Buy the Schneider Electric ZB4FA2 – Reliable Push Button for Industrial Applications
Enhance your control panels with this rugged industrial push button head featuring a durable metal construction and high resistance to environmental factors. Designed with a round shape and a sleek black finish, it mounts flush for a clean look. Certified for IP66, IP67, and IP69K protection, ensuring resistance to dust, water, and high-pressure washdowns. Suitable for demanding applications, it offers long service life with 10 million mechanical cycles, and complies with global safety standards including UL and CSA. Purchase online to guarantee reliable operation in harsh industrial settings.
Buy Schneider Electric ZB4FA2 now and experience unmatched durability and performance in demanding industrial environments.
