Schneider Electric ZB4FA234 Pushbutton Head
The ZB4FA234 is a durable, non-illuminated push-button head designed for industrial control systems. Featuring a round shape with a flush, black operator profile marked 'STOP' in white, it offers reliable operation with a spring return mechanism. Crafted with a chromium-plated metal bezel, it is mounted on a 30.5 mm diameter panel, providing IP66, IP67, IP69, and IP69K protection suitable for harsh environments. Its mechanical durability exceeds 10 million cycles, and it conforms to IEC and UL standards, ensuring safety and longevity in demanding industrial applications.
Schneider Electric ZB4FA234 Pushbutton Head Specifications:
- Bezel material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Head type: Built-in-flush, round shape
- Operator profile: Black flush, 'STOP' white marking
- Mechanical durability: 10,000,000 cycles
- Protection degrees: IP66, IP67, IP69, IP69K
- Temperature range: -40°C to +70°C (-40°F to +158°F)
- Vibration resistance: 5 gn IEC 60068-2-6
- Shock resistance: 30 gn IEC 60068-2-27
- Standards compliance: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA, CE
- Certifications: UL Listed, CSA, EAC
- Sustainable status: Green Premium
- Warranty: 18 months
Buy the Buy Schneider Electric Pushbutton Head Part Number ZB4FA234 Online
Order the Schneider Electric ZB4FA234 pushbutton head online today for a high-quality, durable component designed for industrial control panels. This round, built-in-flush head features a black operator with a white 'STOP' marking, made from chromium-plated metal for corrosion resistance. It offers excellent mechanical durability with over 10 million cycles, and IP66/IP67/IP69/IP69K ratings ensure protection against dust, water, and harsh conditions. Perfect for demanding industrial environments, it complies with IEC, UL, CSA standards, and comes with an 18-month warranty for peace of mind.
Get Schneider Electric ZB4FA234 today—built for reliable industrial control and harsh environment durability.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA234?
You can click on the BUY or RFQ button to purchase ZB4FA234 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA234?
You can download the ZB4FA234 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA234?
Schneider Electric
