Schneider Electric ZB4FA333 Industrial Push Button
The flush-mounted push button head ZB4FA333 features a durable metal construction with a green operator profile and spring return mechanism. Designed for industrial control panels, it has a mounting diameter of 30.5 mm and a round shape suitable for various environments. It offers a mechanical durability of 10 million cycles and conforms to IP66/IP67/IP69 ratings, ensuring protection against dust and water ingress. Certified under UL, CSA, and IEC standards, the device is ideal for demanding industrial applications requiring reliable, non-illuminated push buttons with a sleek chromium-plated finish and versatile mounting options.
Schneider Electric ZB4FA333 Industrial Push Button Specifications:
- Material: Chromium plated metal
- Mounting diameter: 30.5 mm (1.20 in)
- Shape: Round
- Head type: Built-in-flush
- Operator profile: Green, START, white
- Overall width: 36.6 mm (1.44 in)
- Overall height: 36.6 mm (1.44 in)
- Overall depth: 31 mm (1.22 in)
- Mechanical durability: 10,000,000 cycles
- Ingress Protection: IP66/IP67/IP69, Type 13/12/4/4X UL 50E
- IK Degree: IKO6
- Operating temperature: -40°C to +70°C (-40°F to +158°F)
- Vibration resistance: 5 gn, 10-500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms), 25 gn (6 ms) shaker shocks
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA, CE, JIS C8201-5-1, C8201-1
- Certifications: UL Listed, CSA, EAC, REACH compliant, RoHS compliant
Buy the Schneider Electric ZB4FA333 – Reliable Push Button for Industrial Applications
Enhance your industrial control panels with this high-quality flush mounted push button. Constructed from durable metal, it features a green operator with spring return, providing reliable operation in demanding environments. Certified for IP66/IP67/IP69 protection ratings, it withstands dust, water, and shock, ensuring long-term performance. With a lifespan of 10 million cycles and compliance with international standards, it’s ideal for automation, manufacturing, and control systems. Purchase online today to upgrade your industrial control solutions efficiently and confidently.
Buy Schneider Electric ZB4FA333 now and experience unmatched durability, protection, and reliable control for your industrial automation needs.
