Schneider Electric ZB4FA341 industrial pushbutton switch
The ZB4FA341 is a durable, non-illuminated pushbutton head designed for industrial control panels. Featuring a round, built-in-flush design with a green ON profile and white marking, it offers high mechanical durability of 10 million cycles. Compatible with various IEC and UL standards, it provides IP66/IP67/IP69 protection levels and IK06 impact resistance. The device is suitable for harsh environments, with ambient temperature ranges from -40°C to +70°C, and is certified by UL, CSA, and CE. Its compact dimensions include a diameter of 30.5 mm and overall size of 36.6 mm in width and height.
Schneider Electric ZB4FA341 industrial pushbutton switch Specifications:
- Mounting diameter: 30.5 mm (1.20 in)
- Overall width and height: 36.6 mm (1.44 in)
- Depth: 31 mm (1.22 in)
- Head shape: Round, built-in-flush
- Head type: Green flush, ON with white marking
- Material: Chromium plated metal bezel
- Mechanical durability: 10,000,000 cycles
- Protection levels: IP66, IP67, IP69, IP69K
- Impact resistance: IK06
- Temperature range: -40°C to +70°C
- Standards compliance: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA, CE
- Vibration resistance: 5 gn, 10–500 Hz
- Shock resistance: 30 gn for 18 ms, 50 gn for 11 ms
- Certifications: UL Listed, CSA, CE
- Package weight: 1 lb (0.45 kg)
- Packaging: 1 piece per package
- Warranty: 18 months
Buy the Schneider Electric ZB4FA341 – Reliable Pushbutton for Industrial Applications
Purchase the Schneider Electric ZB4FA341 pushbutton switch online today and enjoy high-quality performance in demanding industrial environments. Designed for durability with 10 million cycles of life, this round, green flush-head pushbutton is suitable for control panels, featuring a rugged build that complies with IEC, UL, CSA, and CE standards. Its compact size ensures easy installation, while its IP69 rating offers excellent protection against dust and water. Trust in Schneider Electric for reliable, long-lasting control components that meet demanding industrial specifications.
Get Schneider Electric ZB4FA341 today—built for durability and precise control in harsh environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA341?
You can click on the BUY or RFQ button to purchase ZB4FA341 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA341?
You can download the ZB4FA341 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA341?
Schneider Electric
