Schneider Electric ZB4FA38 Pushbutton Head
The ZB4FA38 is a green flush-mounted pushbutton head designed for use with Harmony XB4 ranges. It features a built-in flush head with a round shape, suitable for insertion of legends, and complies with IP66, IP67, IP69/IP69K protection ratings. Made with chrome-plated metal bezel, it withstands 10 million mechanical cycles and operates within -40°F to 158°F temperature range. It is certified with UL, CSA, and other international standards, suitable for demanding industrial environments requiring durable and flexible control components.
Schneider Electric ZB4FA38 Pushbutton Head Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Material: Chromium plated metal bezel
- Head type: Built-in flush, round shape
- Operator profile: Green flush, spring return
- Mechanical durability: 10,000,000 cycles
- Protection ratings: IP66, IP67, IP69/IP69K, Type 13, 12, 4, 4X UL
- Operating temperature: -40°F to 158°F (-40°C to 70°C)
- Vibration resistance: 5 gn, 10-500 Hz
- Shock resistance: 30 gn, 18 ms; 50 gn, 11 ms
- Certification: UL Listed, CSA, CCC, EAC
- Physical dimensions: Width 2.05 in, Length 2.47 in, Height 1.69 in
- Weight: 0.13 lb (0.06 kg)
- Standards compliance: IEC 60947-5-1, IEC 60947-5-4, UL 508
- Environmental: REACh, RoHS compliant, China RoHS
- Package: 1 piece, weight 1 lb
Buy the Buy Schneider Electric ZB4FA38 Part Number ZB4FA38 Online
Enhance your industrial control panel with the ZB4FA38 green flush-mounted pushbutton head. Designed for durability, it withstands frequent operations with 10 million cycles. Its IP66, IP67, and IP69 ratings ensure excellent protection against dust and water ingress, ideal for harsh environments. The round head with legend insertion allows easy customization. Made from high-quality chrome-plated metal, this component offers long-term reliability and compliance with international safety standards. Purchase online today for seamless integration into your automation system.
Buy Schneider Electric ZB4FA38 now and experience unmatched reliability and performance in industrial control environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA38?
You can click on the BUY or RFQ button to purchase ZB4FA38 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA38?
You can download the ZB4FA38 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA38?
Schneider Electric
