Schneider Electric ZB4FA435 Pushbutton Switch
The ZB4FA435 is a durable, non-illuminated flush mounted pushbutton head with a red OFF white profile, designed for industrial control applications. Constructed with chromium-plated metal bezel, it features a round shape, spring return operation, and a built-in flush head. Suitable for harsh environments, it offers IP66/IP67/IP69/IP69K protection levels, withstands up to 10 million mechanical cycles, and meets multiple safety and quality standards including UL, CSA, and IEC specifications. Its compact size and robust construction make it ideal for control panels requiring reliable signaling interface.
Schneider Electric ZB4FA435 Pushbutton Switch Specifications:
- Range of product: Harmony XB4
- Product or component: Head for non-illuminated push-button
- Device short name: ZBAF
- Bezel material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Head type: Built-in-flush
- Shape of signaling unit: Round
- Head profile: Red flush, OFF white
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Mechanical durability: 10,000,000 cycles
- Protection levels: IP66, IP67, IP69, IP69K
- Vibration resistance: 5 gn at 10-500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms) withstanding 1000 shocks
- Environmental temperature for operation and storage: -40 to +158 °F (-40 to +70 °C)
- IEC standards: IEC 60529, IEC 60068-2-6, IEC 60068-2-27
- Certifications: UL Listed, CSA, CCC, EAC
- Material: Chromium plated metal bezel
- Package weight: 1 lb (0.45 kg)
- Package dimensions: 2.47 in x 2.05 in x 1.69 in
Buy the Buy Schneider Electric ZB4FA435 Part Number ZB4FA435 Online
Secure your control panel with the Schneider Electric Pushbutton Switch ZB4FA435. This robust, non-illuminated flush mounted switch features a chromium-plated metal bezel, round shape, and a red OFF white profile for clear signaling. Designed for harsh environments, it offers IP66/IP67/IP69/IP69K protection, withstands up to ten million cycles, and complies with global safety standards including UL, CSA, and IEC. Its compact size and durable construction ensure long-lasting performance, making it the ideal choice for industrial automation and control applications.
Get Schneider Electric ZB4FA435 today—built for industrial durability and reliable signaling in control panels.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA435?
You can click on the BUY or RFQ button to purchase ZB4FA435 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA435?
You can download the ZB4FA435 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA435?
Schneider Electric
