Schneider Electric ZB4FA5 Flush Metal Push Button
The ZB4FA5 is a durable, flush-mounted metal push button head designed for industrial control applications. It features a yellow, unmarked operator profile with a chrome-plated bezel, and is built to withstand harsh environments with an IP66/IP67/IP69 protection rating. The device is rated for 10 million mechanical cycles, supports a wide temperature range from -40°C to +70°C, and complies with multiple industry standards including UL, CSA, and IEC. Suitable for automation systems, it offers reliable operation in demanding settings.
Schneider Electric ZB4FA5 Flush Metal Push Button Specifications:
- Mounting diameter: 30.5 mm (1.20 in)
- Overall width: 36.6 mm (1.44 in)
- Overall height: 36.6 mm (1.44 in)
- Overall depth: 31 mm (1.22 in)
- Bezel material: Chromium plated metal
- Head type: Built-in flush
- Shape: Round
- Operator profile: Yellow, unmarked
- Mechanical durability: 10,000,000 cycles
- Protection rating: IP66, IP67, IP69
- IK rating: IK06
- Ambient temperature: -40°C to +70°C (-40°F to +158°F)
- Standards compliance: UL, CSA, EN/IEC 60947-5-1, JIS, CE
- Certifications: UL Listed, CSA, EAC
- Vibration resistance: 5 gn IEC 60068-2-6
- Shock resistance: 30 gn IEC 60068-2-27
- Package weight: approx. 0.45 kg (1 lb)
Buy the Buy Schneider Electric ZB4FA5 Part Number ZB4FA5 Online
Purchase the Schneider Electric ZB4FA5 flush-mounted metal push button online today for your industrial control needs. This robust control device features a yellow unmarked operator with a chrome bezel, supporting a mounting diameter of 30.5 mm. It is rated IP69 for dust and water resistance, making it ideal for harsh environments. Designed for long-term durability, it withstands over 10 million cycles and operates reliably across -40°C to +70°C. Order now to enhance your control panels with a high-quality, UL, CSA, and IEC-compliant push button.
Get Schneider Electric ZB4FA5 today—built for industrial automation with high durability, IP69 rating, and reliable switch operation.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA5?
You can click on the BUY or RFQ button to purchase ZB4FA5 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA5?
You can download the ZB4FA5 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA5?
Schneider Electric
