Schneider Electric ZB4FA56 Pushbutton Head
The ZB4FA56 is a non-illuminated, flush-mounted yellow pushbutton head designed for industrial automation and control panels. It features a round shape with a chromium-plated metal bezel and a built-in flip-head operated by a spring return mechanism. Suitable for harsh environments, it offers high mechanical durability of 10 million cycles and an IP66/IP67/IP69 rating for water and dust resistance. Its compact mounting diameter is 30.5 mm, making it ideal for applications requiring reliable push actuators with excellent environmental protection and standard certifications like UL, CSA, and CE.
Schneider Electric ZB4FA56 Pushbutton Head Specifications:
- Material: Chromium plated metal bezel
- Shape: Round
- Head type: Built-in-flush
- Color: Yellow
- Mounting diameter: 30.5 mm
- Overall width: 36.6 mm
- Overall height: 36.6 mm
- Depth: 31 mm
- Mechanical durability: 10,000,000 cycles
- Ingress Protection: IP66, IP67, IP69, IP69K
- Ambient temperature for operation and storage: -40°F to 158°F (-40°C to 70°C)
- Vibration resistance: 5 gn, 10-500 Hz
- Shock resistance: 30 gn, 18 ms
- Certifications: UL, CSA, CE
- Standards: IEC 60947-5-1, IEC 60068-2-6, IEC 60068-2-27
- Package weight: 1 lb (0.45 kg)
- Warranty: 18 months
- Packaging: 1 piece per package
Buy the Buy Schneider Electric ZB4FA56 Part Number ZB4FA56 Online
Enhance your control panels with the Schneider Electric ZB4FA56 yellow flush-mounted pushbutton head, designed for durability and environmental resistance. It features a 30.5 mm diameter mounting, a chromium-plated bezel, and a spring return mechanism, making it suitable for demanding industrial environments. With a mechanical life of 10 million cycles, IP66/IP67/IP69 sealing, and certified safety standards, this pushbutton offers dependable operation for automation, process control, and machinery. Purchase online now for fast delivery and reliable performance.
Buy Schneider Electric ZB4FA56 now and experience unmatched reliability and high environmental resistance for industrial automation controls.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA56?
You can click on the BUY or RFQ button to purchase ZB4FA56 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA56?
You can download the ZB4FA56 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA56?
Schneider Electric
