Schneider Electric ZB4FA58 Pushbutton Head
The yellow flush-mounted pushbutton head is designed for use with Harmony XB4 series control systems. It features a round shape with built-in flush operator profile, ideal for insertion of legends. Made from chromium-plated metal, it offers IP66/67/69 ingress protection and IK06 impact resistance. The head supports mechanical durability of 10 million cycles and is suitable for harsh industrial environments with an ambient temperature range of -40 to 70°C. It includes multiple electrical compositions, such as integral LED options for visual signaling, and complies with IEC, UL, CSA, and CE standards.
Schneider Electric ZB4FA58 Pushbutton Head Specifications:
- Mounting diameter: 30.5 mm
- Overall width: 36.6 mm
- Overall height: 36.6 mm
- Overall depth: 31 mm
- Material: Chromium-plated metal
- Ingress protection: IP66, IP67, IP69
- Impact resistance: IK06
- Mechanical durability: 10,000,000 cycles
- Ambient temperature: -40°C to +70°C
- Electrical options: LED, integral LED, transformer options
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA, CE
- Shock resistance: 30 gn for 18 ms
- Vibration resistance: 5 gn from 10 to 500 Hz
- Package weight: 0.45 kg
- Package dimensions: 4.3 x 5.2 x 6.5 cm
- Certifications: UL Listed, CSA, CCC, EAC
- Materials are RoHS compliant and free of hazardous substances
Buy the Schneider Electric Series Harmony XB4 Pushbutton Head: ZB4FA58
Purchase the Schneider Electric ZB4FA58 pushbutton head online today for high durability, IP66/IP67/IP69 protection, and compatibility with Harmony XB4 series control devices. Designed for harsh industrial environments, this round, yellow head easily supports legend insertion and features built-in illumination LED options. It endures millions of operations, ensuring long-lasting performance in demanding applications. Order now for quick delivery and enhance your control panel efficiency with reliable, certified industrial pushbutton components.
Get Schneider Electric ZB4FA58 today—built with industrial durability and easy legend insertion for reliable control panels.
