Schneider Electric ZB4FA68 Industrial Pushbutton Head
The ZB4FA68 is a blue flush-mounted pushbutton head designed for legend insertion, part of the Harmony XB4 range of industrial control components. This high-durability, built-in-flush signaling unit features a round shape with a 1.20-inch mounting diameter and a 1.44-inch overall width and height. Made from chromium-plated metal, it offers IP66/IP67/IP69K protection, withstands over 10 million cycles, and is suitable for harsh industrial environments with operational temperatures from -40 to 158°F. The device supports multiple electrical compositions with integral LEDs for enhanced visibility.
Schneider Electric ZB4FA68 Industrial Pushbutton Head Specifications:
- Range of product: Harmony XB4
- Head type: Built-in-flush
- Shape: Round
- Color: Blue
- Bezel material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Net weight: 0.13 lb (0.06 kg)
- Mechanical durability: 10,000,000 cycles
- Environmental protection: IP66, IP67, IP69K, Type 13, 12, 4, 4X UL 50E
- Protection class: IK06
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA, CE
- Vibration resistance: 5 gn, 10-500 Hz (IEC 60068-2-6)
- Shock resistance: 30 gn, 18 ms (IEC 60068-2-27)
- Ambient temperature: -40 to 158°F (-40 to 70°C)
- Certifications: UL Listed, CSA, CCC, EAC
- Packaging: 1 unit per package, weight 1 lb, dimensions 2.47 x 2.05 x 1.69 inches, carton weight 0.45 kg
- Sustainable product: Green Premium
- Regulatory compliance: RoHS, REACh, China RoHS
- Chemical safety: Contains Di-isodecyl phthalate (DIDP)
Buy the Schneider Electric ZB4FA68 – Reliable Industrial Control for Legend Insertion
Purchase the Schneider Electric ZB4FA68 today online and ensure reliable operation for your industrial control panels. This durable, IP66/IP67/IP69K rated pushbutton head features legend insertion, supporting harsh environments with a long lifespan of over 10 million cycles. Ideal for applications demanding high protection and visibility, it is easy to install with a 1.20-inch mounting diameter. Order now and equip your projects with high-quality, easy-to-maintain control components designed for efficiency and safety.
Order your Schneider Electric Series ZB4FA68 built-in flush pushbutton head today and enhance your control panel with durable, IP69K rated signaling components.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA68?
You can click on the BUY or RFQ button to purchase ZB4FA68 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA68?
You can download the ZB4FA68 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA68?
Schneider Electric
