Schneider Electric ZB4FA88 Illuminated Push Button
The ZB4FA88 is a yellow, flush-mounted illuminated push button with a round head, designed for industrial control panels. It features a durable chromium-plated metal bezel, a built-in-flush head profile, and an embedded LED indicator for clear operation indication. The device's mounting diameter is 1.20 inches (30.5 mm), with overall dimensions of 1.44 inches by 1.44 inches and a depth of 1.22 inches. It offers high resistance to pressure washing (7,000,000 Pa at 55°C), mechanical durability of 10 million cycles, and protection ratings up to IP69K, suitable for harsh environments. Certified for UL, CSA, CE, and RoHS, it withstands extreme temperatures from -40°F to +158°F (-40°C to +70°C). Its environment resistance, compliance with multiple international standards, and flexible wiring options make it ideal for industrial automation and machinery control applications, providing reliable operation in demanding settings.
Schneider Electric ZB4FA88 Illuminated Push Button Specifications:
- Mounting diameter: 1.20 inches (30.5 mm)
- Overall width: 1.44 inches (36.6 mm)
- Overall height: 1.44 inches (36.6 mm)
- Depth: 1.22 inches (31 mm)
- Bezel material: Chromium plated metal
- Head type: Built-in-flush, round shape
- Operator profile: Yellow flush, unmarked, for insertion of legend
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Mechanical durability: 10,000,000 cycles
- Protection ratings: IP66, IP67, IP69K
- Vibration resistance: 5 gn, 10-500 Hz
- Shock resistance: 30 gn for 18 ms; 50 gn for 11 ms
- Operating temperature: -40°F to +158°F (-40°C to +70°C)
- Certifications: UL Listed, CSA, CE, RoHS, EAC
- Wiring: Suitable for IEC 60947-5-1, IEC 60947-5-4, UL 508 standards
Buy the Buy Schneider Electric ZB4FA88 Push Button Part Number ZB4FA88 Online
Purchase the Schneider Electric ZB4FA88 illuminated push button online today to ensure reliable and durable operation for your industrial control panels. Featuring a yellow flush mount design with an embedded LED indicator, it provides clear signaling in harsh environments. With high protection ratings up to IP69K, robust chromium-plated metal bezel, and resistance to high-pressure water, this push button guarantees longevity and safety in demanding applications. Easy to install and certified for global standards, order now to improve your control system's performance.
Buy Schneider Electric ZB4FA88 push button now and experience unmatched reliability and performance in industrial automation and control systems.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FA88?
You can click on the BUY or RFQ button to purchase ZB4FA88 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FA88?
You can download the ZB4FA88 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FA88?
Schneider Electric
