Schneider Electric ZB4FD201 Selector Switch Head
The ZB4FD201 is a flush-mounted white selector switch head with a 2-position stay-put operator, designed for industrial control panels within the Harmony XB4 range. Its round shape features a chromium-plated metal bezel, mounted through a 1.20-inch diameter hole. The switch head offers IP66, IP67, and IP69 protection ratings, ensuring high resistance to dust, water, and high-pressure cleaning. It withstands mechanical cycles up to 1,000,000 and operates reliably between -40°C to 70°C. Suitable for safety and automation applications, it complies with international standards including IEC 60947 and UL 508. Its rugged construction ensures long-lasting, dependable performance in demanding environments.
Schneider Electric ZB4FD201 Selector Switch Head Specifications:
- Range of product: Harmony XB4
- Device short name: ZB4F
- Head type: Built-in-flush
- Shape of signaling unit: Round
- Head material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.85 in (47 mm)
- Net weight: 0.17 lb (0.078 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C, 0.1m distance
- Mechanical durability: 1,000,000 cycles
- Electrical composition code: C3, C4, CS, C6, C7, C8, C11, C15 depending on contact type
- Ambient air temperature for operation and storage: -40°C to +70°C
- Protection ratings: IP66, IP67, IP69, IP69K, Type 13 UL 50E, Type 12 UL 50E, Type 4 UL 50E, Type 4X UL 50E
- Impact protection: IK06
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, EN/IEC 60068-2-6, IEC 60068-2-27, CSA C22.2 No 14, JIS C8201-5-1, JIS C8201-1
- Certifications: UL Listed, CSA, CCC, EAC
- Vibration resistance: 5 gn, 10–500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms), 25 gn (6 ms) with shocks on all axes
- Packaging: 1 unit per package, package weight 1 lb (0.45 kg), size approximately 2.17 in x 2.05 in x 1.69 in
- Environmental compliance: RoHS, REACH, China RoHS, Pro-active EU RoHS compliance, toxic heavy metal free, mercury free
- Sustainability: Green Premium product
Buy the Buy Schneider Electric ZB4FD201 Selector Switch Head Online
Purchase the Schneider Electric ZB4FD201 selector switch head online to benefit from high durability, IP69 protection, and robust build quality. Its round design and chromium-plated metal bezel make it ideal for industrial control panels requiring reliable 2-position operation. Withstanding up to 1,000,000 mechanical cycles and operating in harsh environments from -40°C to 70°C, this switch ensures long-lasting performance. Buy now to upgrade your automation setup with a product that combines safety certifications, environmental compliance, and superior resistance to water, dust, and impact.
Order your Schneider Electric SeriesZB4FD201 selector switch head today and ensure reliable, high-pressure resistance for your industrial control needs.
