Schneider Electric ZB4FG02 Selector Switch Head
The ZB4FG02 is a flush-mounted selector switch head with a black operator profile and a round shape, designed for industrial control systems. It features a Chromium plated metal bezel, 2-position stay put operation, and a Ronis 455 key lock with right withdrawal. The head supports various mounting and device presentation options, with an IP66/IP67/IP69 rating for high-pressure wash resistance. It is certified according to UL, CSA, CCC, and EAC standards, and offers durability of 1,000,000 mechanical cycles in harsh environments. Suitable for automation and industrial control panels, it ensures reliable operation in demanding conditions.
Schneider Electric ZB4FG02 Selector Switch Head Specifications:
- Bezel material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Shape: Round
- Head type: Built-in-flush
- Operator profile: Black key switch
- Operator position: 2 positions 90°
- Key lock type: Ronis 455, key withdrawal right
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.93 in (49 mm)
- Net weight: 0.29 Ib (0.133 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C, 0.1m distance
- Mechanical durability: 1,000,000 cycles
- Protection ratings: IP66, IP67, IP69, IP69K, Type 13, 12, 4, 4X UL 50E
- IK degree of protection: IKO6
- Ambient temperature for storage/operation: -40°F to 158°F (-40°C to 70°C)
- Standards: EN/IEC 60947-5-1, 5-4, UL 508, IEC 60068-2-6, IEC 60068-2-27
- Certifications: UL Listed, CSA, CCC, EAC
- Vibration resistance: 5 gn, 10-500 Hz
- Shock resistance: 30 gn 18 ms, 50 gn 11 ms, 25 gn 6 ms shocks
- Package weight: 1 lb (0.45 kg)
- Warranty: 18 months
- Environmental compliance: RoHS, REACh, China RoHS, Mercury free
Buy the Schneider Electric Series Harmony XB4 Selector Switch Head: ZB4FG02
Enhance your industrial control system with the durable Schneider Electric ZB4FG02 selector switch head. Featuring a robust chromium plated bezel, IP66/IP67/IP69 ratings, and a 2-position stay put operation, it ensures safe and reliable operation in harsh environments. Its built-in flush mount design and high mechanical durability make it ideal for automation panels and control systems. Purchase online today to upgrade your control panels with a proven, high-quality component that guarantees long-lasting performance and safety in demanding industrial conditions.
Buy Schneider Electric ZB4FG02 now and experience unmatched reliability and performance in industrial control applications.
