Schneider Electric ZB4FG08 Key Selector Switch
The ZB4FG08 is a built-in flush head key selector switch designed for industrial control panels. It features a round shape with a chromium-plated metal bezel, three-position return right to center, and a black key lock operator for reliable operation. Suitable for high-pressure environments with IP67/IP69/IP69K ratings, it withstands mechanical durability of 1,000,000 cycles and is certified to UL, CSA, and CE standards. The switch is ideal for safety and operational control in demanding industrial environments, offering long-lasting performance and secure key operation.
Schneider Electric ZB4FG08 Key Selector Switch Specifications:
- Bezel material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Head type: Built-in-flush
- Shape: Round
- Operator profile: Black key switch
- Key withdrawal position: Left
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.93 in (49 mm)
- Net weight: 0.29 lb (0.133 kg)
- Resistance to high pressure washer: 7000000 Pa at 55°C
- Mechanical durability: 1,000,000 cycles
- Electrical code: C36, C46, C55, C65, C74, C84, C113
- Protection ratings: IP67 IEC 60529, IP69 IEC 60529, IP69K ISO 20653
- Protection classes: UL Type 13, UL Type 12, UL Type 4, UL Type 4X
- IK degree of protection: IK06
- Ambient temperature: -40°C to +70°C
- Vibration resistance: 5 gn 10–500 Hz
- Shock resistance: 30 gn 18 ms
Buy the Buy Schneider Electric Selector Switch Head Part Number ZB4FG08 Online
Purchase the Schneider Electric ZB4FG08 key selector switch online today to ensure reliable operation in your industrial control systems. With a robust round design, built-in flush head, and chromium-plated bezel, it offers exceptional durability and resistance to harsh environments, including high pressure washing and vibration. Certified by UL, CSA, and CE, this switch guarantees safety and long-lasting performance. Ideal for control panels, it features three positions, a black key lock, and IP67/IP69 ratings, making it perfect for demanding industrial applications and safety-critical operations.
Order your Schneider Electric ZB4FG08 secure key selector switch today and enhance your control panel safety with durable, high-performance switching solutions.
