Schneider Electric ZB4FG2 Selector Switch Head
This is a built-in flush-mounted selector switch head with a black key operator profile designed for industrial control panels. It features a round shape, chromium-plated metal bezel, and a stay-put type with two positions at 90°. Its robust construction offers high resistance to high-pressure washing, shocks, and vibrations, suitable for harsh environments. It complies with IEC and UL standards, with IP66/IP67/IP69 protection ratings, and has a mechanical durability of 1 million cycles. Ideal for machinery control and automation systems, it ensures reliable operation in demanding conditions.
Schneider Electric ZB4FG2 Selector Switch Head Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Shape: Round
- Head type: Built-in-flush
- Operator profile: Black key switch
- Type of operator: Stay put
- Positions: 2 at 90°
- Key lock: Ronis 455
- Key withdrawal position: Left
- Bezel material: Chromium plated metal
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.93 in (49 mm)
- Weight: 0.29 lb (0.133 kg)
- Resistance to high-pressure washer: 7,000,000 Pa at 55°C, 0.1m distance
- Mechanical durability: 1,000,000 cycles
- Protection ratings: IP66/IP67/IP69K/IP69
- Vibration resistance: 5 gn IEC 60068-2-6
- Shock resistance: 30 gn IEC 60068-2-27
- Operating temperature: -40°C to +70°C
- Materials: Metal and plastic components
- Standards: IEC 60947-5-1, EN/IEC 60947-5-4, UL 508, CSA
Buy the Buy Schneider Electric ZB4FG2 Selector Switch Head Part Number ZB4FG2 Online
Enhance your control panel with the Schneider Electric ZB4FG2 selector switch head. Designed for durability and precision, it offers high resistance to harsh environments. Its round shape, built-in flush mount, and robust metal bezel ensure seamless integration and reliable operation. Rated IP66/IP67/IP69K/IP69, it withstands high-pressure washing, shocks, and vibrations, making it ideal for industrial machinery and automation systems. Easy to install, this high-quality switch head guarantees safety, durability, and performance in demanding conditions. Perfect for engineers seeking dependable control components.
Order your Schneider Electric ZB4FG2 flush-mounted selector switch head today and ensure reliable control for your industrial automation projects.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FG2?
You can click on the BUY or RFQ button to purchase ZB4FG2 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FG2?
You can download the ZB4FG2 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FG2?
Schneider Electric
