Schneider Electric ZB4FG3 Selector Switch Head
The ZB4FG3 is a flush-mounted selector switch head with a black operator profile designed for industrial control panels. It features a 3-position stay-put operator, Ronis 455 keylock, and a round signaling unit shape. With a mounting diameter of 30.5 mm, its robust construction includes chromium-plated metal bezel and IP66/67/69 protection levels, making it resistant to high-pressure wash, vibration, and shocks. Suitable for demanding environments, it offers high mechanical durability of 1,000,000 cycles and operates within -40 to 70°C, ensuring reliable operation in diverse industrial applications.
Schneider Electric ZB4FG3 Selector Switch Head Specifications:
- Mounting diameter: 30.5 mm (1.20 in)
- Shape of signaling unit: Round
- Head type: Built-in-flush
- Operator profile: Black key switch
- Type of operator: Stay put
- Operator position: 3 positions +/- 45°
- Keylock: Ronis 455, Key withdrawal: Center
- Overall width: 36.6 mm (1.44 in)
- Overall height: 36.6 mm (1.44 in)
- Overall depth: 49 mm (1.93 in)
- Net weight: 0.29 Ib (0.133 kg)
- Protection: IP66, IP67, IP69K (IEC 60529), Type 13/12/4/4X (UL)
- IK degree of protection: IKO6
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Mechanical durability: 1,000,000 cycles
- Environmental temp. – storage & operation: -40°F to 158°F (-40°C to 70°C)
- Certifications: UL Listed, CSA, CCC, EAC
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, EN/IEC 60947-1, JIS C8201-5-1, JIS C8201-1
- Vibration resistance: 5 gn, 10-500 Hz (IEC 60068-2-6)
- Shock resistance: 30 gn/50 gn, IEC 60068-2-27
Buy the Schneider Electric ZB4FG3 – Reliable Selector Switch Head for Industrial Applications
Enhance your industrial control system with the Schneider Electric Selector Switch Head, designed for durability and high performance. Its robust metal construction, IP69K protection, and high mechanical durability ensure reliable operation in harsh environments. The built-in-flush design with a 3-position stay-put operator and Ronis 455 keylock offers precise control and safety. Suitable for high-pressure washing and vibration resistance, this product is ideal for demanding manufacturing and automation applications. Purchase online today for quick, hassle-free integration into your control panels.
Buy Schneider Electric ZB4FG3 now and experience unmatched reliability and performance in demanding industrial environments.
