Schneider Electric ZB4FG9 Key Selector Switch
The ZB4FG9 head for key selector switch is designed for industrial control applications, featuring a built-in-flush head, round shape, and black key switch operator. It supports three positions with ±45° operator positions and has a Ronis 455 keylock for secure operation. Made from chromium plated metal, it offers high resistance to high-pressure washer cleaning at 7000000 Pa, and withstands mechanical cycling up to 1,000,000 cycles. With an IP66/IP67/IP69 protection rating, it meets stringent environmental standards, ensuring durability in harsh industrial environments. The device is suitable for control panels requiring reliable, safe, and durable switching solutions.
Schneider Electric ZB4FG9 Key Selector Switch Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.93 in (49 mm)
- Bezel material: Chromium plated metal
- Head type: Built-in-flush
- Shape: Round
- Operator profile: Black key switch
- Operator positions: 3 positions ±45°
- Keylock: Ronis 455
- Key withdrawal position: Left
- Net weight: 0.29 lb (0.133 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Mechanical durability: 1,000,000 cycles
- Protection ratings: IP66, IP67, IP69K
- Vibration resistance: 5 gn 10...500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms), 25 gn (6 ms) shocks
- Operating temperature: -40 to 158 °F (-40 to 70 °C)
- Standards compliance: EN/IEC 60947-5-1, UL 508, CSA, JIS C8201-5-1
- Certifications: UL Listed, CSA, CCC, EAC
- Warranty: 18 months
Buy the Schneider Electric ZB4FG9 – Reliable Key Selector Switch for Industrial Applications
Purchase the Schneider Electric ZB4FG9 key selector switch online to ensure secure, reliable operation in industrial environments. This robust switch head features high resistance to pressure and shocks, facilitating durability and safety. Its built-in-flush design, round shape, and 3 operator positions make it suitable for various control panel configurations. Certified for IP66/IP67/IP69 protection standards, it withstands harsh conditions including high-pressure washing and vibrations. Enjoy fast, convenient online ordering with 18 months warranty, ensuring quality and peace of mind for your industrial automation needs.
Get Schneider Electric ZB4FG9 today—built for precision and long-lasting durability in control panel solutions.
