Schneider Electric ZB4FH053 Illuminated Push-Button
This is a built-in-flush, illuminated push-button head designed for round, 22mm signaling units with orange flush illumination, suitable for industrial environments. It features a chromium-plated metal bezel, mechanical durability of 500,000 cycles, and resistance to high pressure washing up to 7,000,000 Pa at 55°C. Certified for IP66/IP67/IP69/IP69K, it supports multiple standards including IEC and UL configurations, ensuring robust performance in demanding applications. Compatible with various control systems, it incorporates integral LED indicators for clear signaling. Ideal for industrial automation, control panels, and machinery requiring reliable, visible push button operation.
Schneider Electric ZB4FH053 Illuminated Push-Button Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Bezel material: Chromium plated metal
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Net weight: 0.13 lb (0.058 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C, 0.1 m distance
- Mechanical durability: 500,000 cycles
- IP ratings: IP66, IP67, IP69, IP69K
- Protection class: Class I IEC 60536
- Ambient temperature for operation and storage: -40°F to 158°F (-40°C to 70°C)
- Vibration resistance: 5 gn IEC 60068-2-6
- Shock resistance: 30 gn IEC 60068-2-27, 50 gn shocks on each axis
- Certifications: UL Listed, CSA, CCC, EAC
- Standard compliance: IEC 60947-5-1, UL 508, JIS C8201-5-1
- Warranty: 18 months
Buy the Buy Schneider Electric Pushbutton Part Number ZB4FH053 Online
Purchase the Schneider Electric illuminated push-button ZB4FH053 online today to ensure durable, high-quality control in your industrial applications. Featuring a round, 22mm size, it offers built-in LED illumination with orange flush lighting for clear visibility. Its robust design withstands high pressure washing, vibration, and impact, conforming to IP66/IP67/IP69/IP69K standards. Ideal for automation and machinery control, it ensures safety, reliability, and ease of operation while supporting multiple standards for versatile installation. Order now for quick delivery and professional performance.
Order your Schneider Electric Series ZB4FH053 orange flush illuminated push-button today and enhance your control panel for reliable signaling.
