Schneider Electric ZB4FH063 Illuminated Pushbutton
The blue flush-mounted illuminated pushbutton head is designed for easy integration into control panels and equipment, featuring a round shape with a 1.20-inch diameter. It supports integral LED lighting, offers high durability with 500,000 cycles, and withstands harsh environments with an IP66/IP67/IP69/IP69K degree of protection. Suitable for industrial applications, it complies with IEC, UL, and CSA standards, and features a chromium-plated metal bezel for robustness. Ideal for signaling and control functions in automation systems, it ensures reliable operation under demanding conditions.
Schneider Electric ZB4FH063 Illuminated Pushbutton Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.22 in (31 mm)
- Bezel material: Chromium plated metal
- Shape: Round
- Type of operator: push-push
- Head for illumination: Integral LED
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Mechanical durability: 500,000 cycles
- Electrical protection class: Class IEC 60536
- IP rating: IP66, IP67, IP69, IP69K (ISO 20653)
- IK degree of protection: IKO6 (IEC 50102)
- Standards: UL 508, CSA, IEC 60947 series, JIS C8201, CE
- Certifications: UL Listed, CSA, CCC, EAC
- Vibration resistance: 5 gn, 10-500Hz (IEC 60068-2-6)
- Shock resistance: 30 gn for 18ms, 50 gn for 11ms, 25 gn for 6ms (IEC 60068-2-27)
- Operating temperature: -40°F to 158°F (-40°C to 70°C)
- Storage temperature: -40°F to 158°F (-40°C to 70°C)
- Package weight: 1 lb (0.45 kg)
- Warranty: 18 months
Buy the Buy Schneider Electric ZB4FH063 Part Number ZB4FH063 Online
Enhance your control panels with this durable blue illuminated pushbutton featuring integral LED lighting for clear signaling. Constructed with chromium-plated metal, it offers IP66/IP67/IP69/IP69K protection, withstands harsh environments, and endures up to 500,000 cycles. Its standardized IEC, UL, and CSA certifications ensure safety and quality. Easy to install with a 1.20-inch mounting diameter, it's ideal for automation systems requiring reliable and visible signaling in industrial applications. Optimize your control solutions today by purchasing online.
Buy Schneider Electric ZB4FH063 now and experience unmatched reliability and performance in industrial control systems.
