Schneider Electric ZB4FH1 Pushbutton Control
The ZB4FH1 is a non-illuminated, white projecting pushbutton head designed for industrial control panels. It features a round shape with a built-in-flush operator profile, mounted on a chromium-plated metal bezel with a mounting diameter of 30.5 mm. The device supports mechanical durability of 500,000 cycles and conforms to multiple IP ratings, including IP66, IP67, and IP69K, ensuring excellent protection against dust and water. Suitable for environments with temperatures from -40°C to 70°C, it meets various safety and quality standards, including UL, CSA, CE, and IEC certifications.
Schneider Electric ZB4FH1 Pushbutton Control Specifications:
- Shape: Round
- Head type: Built-in flush
- Color: White
- Bezel material: Chromium plated metal
- Mounting diameter: 30.5 mm
- Overall dimensions: Width 36.6 mm, Height 36.6 mm, Depth 33 mm
- Mechanical durability: 500,000 cycles
- IP ratings: IP66, IP67, IP69K
- Protection class: Class I IEC 60536
- Operating temperature: -40°C to 70°C
- Vibration resistance: 5 gn, 10-500 Hz IEC 60068-2-6
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms) IEC 60068-2-27
- Standards compliance: UL, CSA, CE, IEC 60947-5-1, JIS C8201-5-1
- Certifications: UL Listed, CSA, CE, EAC, RoHS compliant
- Package weight: 0.45 kg
- Warranty: 18 months
Buy the Buy Schneider Electric ZB4FH1 Part Number ZB4FH1 Online
Experience the reliability of the Schneider Electric ZB4FH1 non-illuminated white pushbutton head, designed for industrial control panels requiring durable and high-performance components. With a built-in-flush design, this round control device features a chromium-plated metal bezel, providing an elegant and corrosion-resistant finish. Its rugged construction supports up to 500,000 cycles, with IP66, IP67, and IP69K protection ratings, making it suitable for harsh environments. Certified to UL, CSA, and IEC standards, it guarantees safety, compliance, and long-lasting operation for user confidence.
Buy Schneider Electric ZB4FH1 now and ensure robust, industrial-grade control with IP69K rated protection and long-lasting durability.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FH1?
You can click on the BUY or RFQ button to purchase ZB4FH1 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FH1?
You can download the ZB4FH1 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FH1?
Schneider Electric
