Schneider Electric ZB4FH3 Pushbutton Head
The ZB4FH3 is a green, non-illuminated, flush-mounted pushbutton head designed for industrial control panels. Crafted with a chromium-plated metal bezel, it features a round shape with a push-push operator profile. The device supports multiple mounting standards and offers high durability with 500,000 mechanical cycles. It is rated IP66, IP67, IP69, and complies with multiple international safety standards, including UL, CSA, and IEC. Suitable for demanding environments, it withstands ambient temperatures from –40°C to 70°C and resist vibration and shocks, making it ideal for automation and process control applications.
Schneider Electric ZB4FH3 Pushbutton Head Specifications:
- Color: Green
- Bezel Material: Chromium plated metal
- Mounting Diameter: 1.20 in (30.5 mm)
- Overall Width: 1.44 in (36.6 mm)
- Overall Height: 1.44 in (36.6 mm)
- Overall Depth: 4.30 in (33 mm)
- Mechanical Durability: 500,000 cycles
- Ambient Temperature for Storage and Operation: -40°C to 70°C (~40°F to 158°F)
- Ingress Protection: IP66, IP67, IP69, Type 13, 12, 4, 4X, IK06
- Vibration Resistance: 5 gn, 10-500 Hz
- Shock Resistance: 30 gn for 18 ms, 50 gn for 11 ms, 25 gn 6 ms shocks
- Certifications: UL Listed, CSA, CE, EAC
- Standards Compliance: IEC 60536, IEC 60529, IEC 50102, IEC 60947-5-1, IEC 60947-5-4, UL 508, JIS C8201, CSA C22.2 No 14
- Package Weight: 1 lb (0.45 kg)
- Environmental: RoHS compliant, REACH compliant, toxic heavy metal free, mercury free
- Warranty: 18 months
Buy the Schneider Electric ZB4FH3 – Reliable Pushbutton for Industrial Applications
Enhance your control panels with the Schneider Electric ZB4FH3 pushbutton head. Featuring a durable chromium-plated bezel and high IP ratings, it offers reliable operation in demanding environments. Suitable for automation, process control, and industrial machinery, this pushbutton endures extensive cycle life and resists vibration and shocks. Easy to install with a mounting diameter of 30.5 mm, it is compatible with various industrial standards and safety certifications, ensuring dependable performance and compliance for your critical applications.
Order your Schneider Electric ZB4FH3 flush-mounted green pushbutton today and ensure high durability and safety in your automation projects.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FH3?
You can click on the BUY or RFQ button to purchase ZB4FH3 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FH3?
You can download the ZB4FH3 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FH3?
Schneider Electric
