Schneider Electric ZB4FH43 Industrial Push Button
The ZB4FH43 is a flush-mounted red projecting illuminated push button with integral LED, designed for industrial control applications. It features a round head with push-push operation, built-in flush profile, and a mounting diameter of 30.5 mm. Crafted from chromium-plated metal, it offers IP66/IP67/IP69 protection, suitable for harsh environments. It resists high-pressure washing up to 7,000,000 Pa and endures 500,000 mechanical cycles. Certified by UL, CSA, and IEC standards, it ensures reliable performance for demanding industrial settings, providing clear visual signaling and durability in various environments.
Schneider Electric ZB4FH43 Industrial Push Button Specifications:
- Head type: Built-in-flush
- Shape of signaling unit: Round
- Operator profile: Red projecting, unmarked
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 4.30 in (33 mm)
- Net weight: 0.13 Ib (0.058 kg)
- Protection: IP66, IP67, IP69, IK06
- Mechanical durability: 500000 cycles
- Electrical protection class: Class I IEC 60536
- Operating temperature: -40 to +70°C
- Vibration resistance: 5 gn 10...500 Hz
- Shock resistance: 30 gn 18 ms
- Certifications: UL Listed, CSA, EAC
- Material: Chromium plated metal
- Environmental protection: CE, JIS, UL standards
Buy the Schneider Electric ZB4FH43 – Reliable Industrial Push Button for Industrial Applications
Enhance your control system with the Schneider Electric ZB4FH43 industrial push button, featuring a durable, flush-mounted design with integrated LED. Its IP66/IP67/IP69 protection ratings make it ideal for harsh environments, resisting high-pressure washing and mechanical wear. Certified by UL, CSA, and IEC standards, it guarantees safety, reliability, and long-lasting performance. Easy to install with a 30.5 mm mounting diameter, it offers clear visual signaling for industrial applications, ensuring operational safety and efficiency for demanding control and automation needs.
Order your Schneider Electric ZB4FH43 industrial push button today and ensure dependable signaling in your control panels and harsh environments.
