Schneider Electric ZB4FH83 Illuminated Push-Button
The ZB4FH83 is a flush-mounted yellow illuminated push-button with a projecting head, designed for industrial control applications. It features a round shape with a built-in-flush head and a mounting diameter of 1.20 inches (30.5 mm). The device is made of chromium-plated metal and incorporates integral LEDs for visual signaling. It offers high resistance to impact, vibration, and high-pressure washdowns, adhering to strict IP66, IP67, and IP69K protection standards. Suitable for harsh environments, it ensures reliable operation with a mechanical durability of 500,000 cycles and compliance with IEC and UL standards, making it ideal for control stations and automation systems.
Schneider Electric ZB4FH83 Illuminated Push-Button Specifications:
- Color: Yellow
- Bezel material: Chromium plated metal
- Head type: Built-in-flush
- Shape: Round
- Mounting diameter: 1.20 inches (30.5 mm)
- Overall width: 1.44 inches (36.6 mm)
- Overall height: 1.44 inches (36.6 mm)
- Overall depth: 1.30 inches (33 mm)
- Net weight: 0.13 Ib (0.058 kg)
- Protection rating: IP66, IP67, IP69K conforming to IEC 60529
- Impact resistance: 30 gn at 18 ms, IEC 60068-2-27
- Vibration resistance: 5 gn, 10-500 Hz, IEC 60068-2-6
- Shock resistance: 50 gn at 11 ms, IEC 60068-2-27
- Electrical: IEC 60536 Class |, UL 508 compliant
- Mechanical durability: 500,000 cycles
- Operating temperature: -40°F to 158°F (-40°C to 70°C)
- Certifications: UL Listed, CSA, ccc, EAC
Buy the Schneider Electric Series XB4 Yellow Illuminated Push-Button: ZB4FH83
Purchase the Schneider Electric Series XB4 ZB4FH83 yellow illuminated push-button online today to enhance your control panels. Its robust construction, high impact and vibration resistance, and IP69K protection ensure durability in harsh environments. With an integrated LED for clear visual indication, it supports reliable operation over hundreds of thousands of cycles. Perfect for automation, control stations, and industrial machinery, this push-button combines durability with excellent visibility. Secure your supply now for dependable control solutions that meet industry standards.
Order your Schneider Electric Series XB4 ZB4FH83 yellow illuminated push-button today and ensure reliable, high-quality control in your industrial automation projects.
