Schneider Electric ZB4FK1243 Selector Switch
The ZB4FK1243 is a flush-mounted red illuminated selector switch head with a round shape, designed for industrial control applications. It features a built-in flush head with a stay-put, two-position operator profile at 90°, and a mounting diameter of 1.20 inches (30.5 mm). The switch offers high mechanical durability with 1,000,000 cycles, electromagnetic resistance, and IP66/IP67/IP69/IP69K ratings for excellent protection against dust, water, and high-pressure washdowns. Compatible with various electrical compositions and standards, this selector switch ensures reliability in demanding environments. Its corrosion-resistant chromium-plated metal bezel enhances durability and aesthetics.
Schneider Electric ZB4FK1243 Selector Switch Specifications:
- Shape of signaling unit: Round
- Type of operator: Stay put
- Head type: Built-in-flush
- Bezel material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.85 in (47 mm)
- Net weight: 0.17 Ib (0.078 kg)
- Electrical composition code: M3, M6, M10, M4 options with integral LED
- Protection rating: IP66, IP67, IP69, IP69K, Type 13, 12, 4, 4X UL 50E
- Vibration resistance: 5 gn 10-500 Hz
- Shock resistance: 30 gn (18 ms) IEC 60068-2-27
- Temperature range: -40°C to +70°C (-40°F to 158°F)
- Certifications: UL Listed, CSA, CCC, EAC
- Mechanical durability: 1,000,000 cycles
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, CE, JIS C8201-5-1/1
- Wiring: Front mounting with integral LED, transformer options available
- Package weight: 1 lb (0.45 kg)
- Package dimensions: Height 1.69 in, Width 2.05 in, Length 2.47 in
Buy the Schneider Electric Series Harmony XB4 Selector Switch: ZB4FK1243
Purchase the Schneider Electric Selector Switch ZB4FK1243 online today. Designed for robust industrial control panels, this durable round switch features a built-in flush head, IP66/IP67/IP69 ratings, and a stay-put two-position operator. Its corrosion-resistant chromium bezel, high mechanical durability with over a million cycles, and LED compatibility make it ideal for harsh environments. Easy to install with front mounting options, it complies with IEC, UL, CSA, and CE standards. Enhance your control system reliability by ordering this reliable switch online now.
Get Schneider Electric ZB4FK1243 today—built for durability in demanding industrial control environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FK1243?
You can click on the BUY or RFQ button to purchase ZB4FK1243 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FK1243?
You can download the ZB4FK1243 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FK1243?
Schneider Electric
