Schneider Electric ZB4FK1253 Industrial Selector Switch
The ZB4FK1253 is a flush-mounted orange illuminated selector switch designed for industrial control panels. It features a robust metal bezel, built-in-flush head with a stay-put operator, and is suitable for various environments with IP66/IP67/IP69 protection ratings. Its 2-position operation with 90° operator rotation ensures reliable manual control. The switch’s compact dimensions and high mechanical durability make it ideal for demanding industrial applications, including those requiring high pressure washer resistance and compliance with multiple safety standards such as UL, CSA, and IEC.
Schneider Electric ZB4FK1253 Industrial Selector Switch Specifications:
- Bezel material: Chromium plated metal
- Head type: Built-in-flush
- Mounting diameter: 1.20 inches (30.5 mm)
- Shape: Round signaling unit
- Operator profile: Orange standard handle
- Operator positions: 2 positions 90°
- Overall width & height: 1.44 inches (36.6 mm)
- Depth: 1.85 inches (47 mm)
- Net weight: 0.17 lb (0.078 kg)
- Resistance: High-pressure washer resistant up to 7,000,000 Pa at 55°C, 0.1 m distance
- Mechanical durability: 1,000,000 cycles
- Protection ratings: IP66, IP67, IP69, IK06
- Standards: UL, CSA, EN/IEC 60947-5-1, JIS, CE
- Vibration resistance: 5 gn 10-500 Hz
- Shock resistance: 30 gn for 18 ms, 50 gn for 11 ms, 25 gn 6 ms shocks
- Warranty: 18 months
Buy the Buy Schneider Electric ZB4FK1253 Part Number ZB4FK1253 Online
Order the Schneider Electric industrial selector switch ZB4FK1253 online today to ensure reliable manual control in your automation systems. This high-durability switch features a robust metal bezel, a built-in flush head, and a 2-position stay-put operator, suitable for demanding environments. Its IP69 rating guarantees protection against water, dust, and high-pressure cleaning. Ideal for machinery panels, control stations, and safety systems, this compact yet durable switch meets global standards, offering excellent operational lifespan and seamless integration for industrial applications. Purchase now for fast delivery and guaranteed quality.
Buy Schneider Electric ZB4FK1253 now and experience unmatched reliability and high-performance industrial control solutions.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FK1253?
You can click on the BUY or RFQ button to purchase ZB4FK1253 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FK1253?
You can download the ZB4FK1253 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FK1253?
Schneider Electric
