Schneider Electric ZB4FK1343 Industrial control switch
The ZB4FK1343 is a flush-mounted, 3-position red illuminated selector switch head designed for industrial control panels. It features a round shape with a stainless steel bezel, built-in-flush head type, and operator profile that stays put in three positions with ±45° adjustment. The device supports multiple electrical configurations with integral LEDs, has a mounting diameter of 30.5 mm, and provides high resistance to water, dust, and mechanical wear with an IP66/IP67/IP69 rating and durability of over one million cycles. Suitable for harsh environments, it conforms with IEC, UL, CSA, and CE standards, making it ideal for automation, machinery, and safety applications.
Schneider Electric ZB4FK1343 Industrial control switch Specifications:
- Range of product: Harmony XB4
- Type: Built-in-flush head for illuminated selector switch
- Shape: Round
- Mounting diameter: 1.20 in (30.5 mm)
- Operator profile: Red standard handle with 3 positions ±45°
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.85 in (47 mm)
- Net weight: 0.17 Ib (0.078 kg)
- Resistance to high-pressure washer: 7,000,000 Pa at 55°C
- Mechanical durability: 1,000,000 cycles
- Electrical Composition Codes: M3, M6, M10, M4 with integral LED options
- Protection: IP66/IP67/IP69, UL Type 12/13/4/4X, IK06
- Standards: CSA, EN/IEC 60947-5-1, 5-4, UL 508, JIS, CE
- Vibration resistance: 5 gn 10-500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms)
- Temperature range for operation/storage: -40°F to 158°F (-40°C to 70°C)
- Certifications: UL Listed, CSA, CCC, EAC
- Environmental: RoHS, REACh, Toxic heavy metal free
- Warranty: 18 months
Buy the Buy Schneider Electric ZB4FK1343 Control Switch Part Number ZB4FK1343 Online
Purchase the Schneider Electric ZB4FK1343 industrial control switch online for reliable and durable operation. Designed with a robust metallic bezel, integrated LED illumination, and an IP69 rating, this switch ensures optimal safety and performance in demanding industrial applications. Easy to install with a 30.5 mm mounting diameter, it supports high resistance to environmental factors, mechanical wear, and electrical surges. Perfect for automation, machinery, and safety systems, it guarantees long-term functionality, compliance with international standards, and excellent value for industrial control needs.
Get Schneider Electric ZB4FK1343 today—built for precision and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FK1343?
You can click on the BUY or RFQ button to purchase ZB4FK1343 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FK1343?
You can download the ZB4FK1343 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FK1343?
Schneider Electric
