Schneider Electric ZB4FK1443 Industrial Selector Switch
The ZB4FK1443 is a flush-mounted red illuminated selector switch head designed for industrial control panels and automation systems. It features a built-in-flush head with a round shape, suitable for right-to-left spring return operation, with two positions at 90°. Constructed from chromium-plated metal, it offers IP66, IP67, IP69K, and UL 50E environmental protection ratings. It withstands mechanical durability of 500,000 cycles and resistance to high-pressure washing up to 7,000,000 Pa at 55°C. Its compact size and high resilience make it ideal for demanding industrial environments, conforming to safety and quality standards like IEC, UL, and CSA.
Schneider Electric ZB4FK1443 Industrial Selector Switch Specifications:
- Mounting diameter: 1.20 in (30.5 mm)
- Shape: Round
- Head type: Built-in-flush
- Operator profile: Red standard handle, 2 positions 90°
- Overall width: 1.44 in (36.6 mm), height: 1.44 in (36.6 mm), depth: 1.85 in (47 mm)
- Net weight: 0.17 Ib (0.078 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Mechanical durability: 500,000 cycles
- Environmental protection: IP66, IP67, IP69, UL Type 13,12,4,4X
- Vibration resistance: 5 gn 10...500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms) on each axis
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA C22.2 No 14, CE, JIS C8201-5-1, C8201-1
- Certifications: UL Listed, CSA, CCC, EAC
- Temperature Range: -40°F to 158°F (-40°C to 70°C)
- Protection rating: IP66/IP67/IP69/IP69K, UL Type 13,12,4,4X
- Impact resistance: IK06
Buy the Buy Schneider Electric ZB4FK1443 Control Switch Part Number ZB4FK1443 Online
Enhance your automation setup with the Schneider Electric ZB4FK1443 industrial selector switch, featuring robust construction, high pressure wash resistance, and multiple environmental protections. Perfect for demanding applications requiring reliable operation and visibility. Easy to install with a 30.5 mm diameter mounting, its round shape and 2-position operation ensure smooth control. Trust this UL-listed, CSA, and CE certified device for safety, longevity, and seamless integration into your control panel for industrial automation, machinery, or manufacturing systems.
Get Schneider Electric ZB4FK1443 illuminated selector switch today—built for durability and demanding industrial environments.
