Schneider Electric ZB4FK1463 Illuminated Selector Switch
The ZB4FK1463 is a round, flush-mounted blue illuminated selector switch head designed for industrial control applications. It features a 2-position operator with right to left spring return, a mounting diameter of 1.20 inches (30.5 mm), and conforms to IP66, IP67, IP69, and IP69K standards for protection. The switch has a built-in integral LED, withstands mechanical durability of 500,000 cycles, and resists high-pressure washing at 7,000,000 Pa. Suitable for harsh environments, it complies with UL, CSA, CE, and other safety standards, ensuring reliable operation in automation systems.
Schneider Electric ZB4FK1463 Illuminated Selector Switch Specifications:
- Mounting Diameter: 1.20 in (30.5 mm)
- Overall Width: 1.44 in (36.6 mm)
- Overall Height: 1.44 in (36.6 mm)
- Overall Depth: 1.85 in (47 mm)
- Material: Chromium plated metal bezel
- Head Type: Built-in-flush
- Operator Profile: Blue standard handle
- Number of Positions: 2
- Position Angle: 90°
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Mechanical Durability: 500,000 cycles
- Ingress Protection: IP66, IP67, IP69, IP69K
- Vibration Resistance: 5 gn, 10-500 Hz
- Shock Resistance: 30 gn for 18 ms, 50 gn for 11 ms
- Certifications: UL Listed, CSA, CCC, EAC
- Operating Temperature: -40°F to 158°F (-40°C to 70°C)
- Warranty: 18 months
- Compliance: IEC 60947-5-1, UL 508, JIS C8201-5-1
Buy the Buy Schneider Electric ZB4FK1463 Part Number ZB4FK1463 Online
Purchase the Schneider Electric illuminated selector switch ZB4FK1463 online today for reliable performance in demanding environments. Its robust design, 2-position operation, and built-in LED provide clear signals and ease of use in automation systems. Suitable for harsh conditions with IP69K protection, it withstands high-pressure cleaning and heavy-duty use. Enjoy quick delivery, secure checkout, and the assurance of a 18-month warranty. Upgrade your control station effortlessly by ordering this high-quality switch from our online store now.
Buy Schneider Electric ZB4FK1463 now and enhance your industrial control panel with a durable, high-pressure wash-resistant selector switch.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FK1463?
You can click on the BUY or RFQ button to purchase ZB4FK1463 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FK1463?
You can download the ZB4FK1463 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FK1463?
Schneider Electric
