Schneider Electric ZB4FK1483 Industrial Selector Switch
The ZB4FK1483 is a flush-mounted yellow selector switch with a round signaling head designed for industrial control panels. It features integral LEDs for clear operation indication, with a built-in-flush head and high resistance to environmental factors like high-pressure washing, withstanding pressures up to 7,000,000 Pa. The switch offers two positions at 90°, is rated IP66/IP67/IP69/IP69K for superior protection, and complies with multiple standards including IEC 60947-5-1 and UL 508. Its durable construction supports 500,000 mechanical cycles, making it ideal for demanding industrial environments requiring reliable control solutions.
Schneider Electric ZB4FK1483 Industrial Selector Switch Specifications:
- Mounting Diameter: 1.20 inches (30.5 mm)
- Head Type: Built-in flush round signaling unit
- Shape of Signaling Unit: Round
- Color: Yellow
- Operator Positions: 2 positions at 90°
- Overall Width: 1.44 inches (36.6 mm)
- Overall Height: 1.44 inches (36.6 mm)
- Overall Depth: 1.85 inches (47 mm)
- Weight: 0.17 lb (0.078 kg)
- Resistance to High Pressure Washer: 7,000,000 Pa at 55°C
- Mechanical Durability: 500,000 cycles
- Ingress Protection: IP66, IP67, IP69, IP69K according to IEC 60529
- Vibration Resistance: 5 gn, 10-500 Hz
- Shock Resistance: 30 gn (18 ms), 50 gn (11 ms), 25 gn for 1000 shocks per axis
- Standards Compliance: CSA, EN/IEC 60947-5-1, UL 508, JIS C8201-5-1, CE
- Environmental Ratings: -40°F to 158°F (-40°C to 70°C)
- Warrant Duration: 18 months
- Protection Category: Type 12, Type 13, Type 4, Type 4X UL 50E
- Certifications: UL Listed, CSA, CCC, EAC
- Environmental Regulations: RoHS, China RoHS, PRO-EU RoHS compliant
- Toxic Metal Free: Yes, Mercury Free: Yes
Buy the Schneider Electric Series Harmony XB4 Yellow Selector Switch: ZB4FK1483
Order the Schneider Electric ZB4FK1483 industrial yellow selector switch online today. Designed for reliable operation with integral LED indication, high protection ratings, and durability of 500,000 cycles. Its IP69 rating ensures excellent resistance to dust and water, suitable for demanding environments. This switch features a 1.20-inch mounting diameter, 2-position operation at 90°, and complies with international safety standards like IEC 60947-5-1 and UL 508. Invest in this robust control component to enhance your machine safety and operational efficiency.
Get Schneider Electric ZB4FK1483 today—built for precision, high environmental resistance, and long-lasting durability in industrial control systems.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FK1483?
You can click on the BUY or RFQ button to purchase ZB4FK1483 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FK1483?
You can download the ZB4FK1483 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FK1483?
Schneider Electric
