Schneider Electric ZB4FK1533 Selector Switch Head
The ZB4FK1533 is a flush-mounted green illuminated selector switch head with a three-position return to center feature, designed for industrial control panels. It offers rugged IP66, IP67, and IP69 protection, making it suitable for harsh environments. Its 1.20-inch mounting diameter, built-in-flush head, and robust chromium-plated metal bezel ensure durability. The switch's multiple electrical combinations include integral LEDs and transformers. It withstands mechanical durability of 500,000 cycles and high-pressure washer resistance of 7,000,000 Pa at 55°C. The device features environment-resistant construction, compact dimensions, and compliance with IEC, UL, CSA, and CE standards for reliable, long-lasting industrial operation.
Schneider Electric ZB4FK1533 Selector Switch Head Specifications:
- Range of product: Harmony XB4
- Type: Head for illuminated selector switch
- Head type: Built-in-flush
- Mounting diameter: 1.20 inches (30.5 mm)
- Shape: Round
- Operator profile: Green standard handle
- Number of positions: 3 positions +/- 45°
- Overall width: 1.44 inches (36.6 mm)
- Overall height: 1.44 inches (36.6 mm)
- Overall depth: 1.85 inches (47 mm)
- Net weight: 0.17 lb (0.078 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C, 0.1m distance
- Mechanical durability: 500,000 cycles
- Electrical composition: M3, M6, M10, M4 configurations with integral LEDs and transformers
- Protection ratings: IP66, IP67, IP69, IP69K per IEC 60529
- Vibration resistance: 5 gn IEC 60068-2-6
- Shock resistance: 30 gn IEC 60068-2-27
- Environmental protection: UL, CSA, CE, JIS standards compliance
- Temperature range: -40°F to 158°F (-40°C to 70°C)
- Standards: IEC, UL, CSA, JIS, CE
- Warranty: 18 months
Buy the Buy Schneider Electric ZB4FK1533 Part Number ZB4FK1533 Online
Purchase the Schneider Electric Selector Switch Head ZB4FK1533 online today and enjoy fast delivery of a high-quality, durable switch designed for harsh environments. With multiple electrical configurations, environmental resistance, and IP66/IP67/IP69 protection ratings, this switch ensures reliable operation in industrial applications. Its robust construction withstands high-pressure washing and extensive cycling, making it ideal for demanding control panel setups. Get this versatile, environmentally resistant, and UL, CSA compliant switch to improve your automation systems with confidence and efficiency.
Order your Schneider Electric ZB4FK1533 switch head today and enhance your control panels with reliable, durable industrial components.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FK1533?
You can click on the BUY or RFQ button to purchase ZB4FK1533 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FK1533?
You can download the ZB4FK1533 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FK1533?
Schneider Electric
