Schneider Electric ZB4FK1563 Illuminated Selector Switch
The blue illuminated selector switch head features a built-in flush mounted design with a 3-position return to center spring mechanism, suitable for industrial control applications. It conforms to IP66, IP67, IP69, and IP69K protection standards, ensuring high resistance to pressure washing, vibration, and shock. The switch supports multiple electrical configurations with integral LEDs, and its durable construction withstands harsh environments from -40°F to 158°F. Certified by UL, CSA, and CE, it offers reliable performance for automation and control systems with a standard mounting diameter of 30.5 mm and a weight of 0.17 lb.
Schneider Electric ZB4FK1563 Illuminated Selector Switch Specifications:
- Range of product: Harmony XB4
- Head type: Built-in-flush
- Color: Blue
- Shape of signaling unit: Round
- Mounting diameter: 1.20 in (30.5 mm)
- CAD overall width: 1.44 in (36.6 mm)
- CAD overall height: 1.44 in (36.6 mm)
- CAD overall depth: 1.85 in (47 mm)
- Net weight: 0.17 lb (0.078 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C, 0.1m distance
- Mechanical durability: 500,000 cycles
- Electrical composition code: M3, M6, M10, M4 (with integral LED and transformer options)
- Ambient air temperature for storage and operation: -40°F to 158°F (-40°C to 70°C)
- Protection: IP66, IP67, IP69, IP69K, Type 13 UL 50E, Type 12 UL 50E, Type 4 UL 50E, Type 4X UL 50E
- IK degree of protection: IKO6
- Standards: CSA, EN/IEC 60947-5-1, UL 508, JIS C8201-5-1, CE
- Vibration resistance: 5 gn, 10-500 Hz, IEC 60068-2-6
- Shock resistance: 30 gn for 18 ms, IEC 60068-2-27
- Certifications: UL Listed, CSA, CCC, EAC
- Package weight: 1 lb (0.45 kg)
- Warranty: 18 months
Buy the Schneider Electric Series Harmony XB4 Blue Illum Selector Switch ZB4FK1563
Order the Schneider Electric illuminated selector switch with a blue LED today for robust control solutions. Designed for demanding environments, it features a 3-position operation with flush mounting, IP69K protection, and a durable metal bezel. Suitable for automating manufacturing processes, its certifications ensure compliance with UL, CSA, and IEC standards. Easy to install with a 30.5 mm diameter, this switch offers long-lasting performance against shocks, vibrations, and harsh conditions. Enhance your control panels with this reliable, high-quality component available for online purchase now.
Buy Schneider Electric ZB4FK1563 now and experience unmatched reliability and performance in industrial control equipment.
