Schneider Electric ZB4FK1833 Selector Switch Head
The Green Illum Selector Switch Head is designed for flush mounting within the Harmony XB4 series, featuring a 3-position return right to center with a built-in green LED indicator. It is constructed from chromium plated metal bezel and has a mounting diameter of 1.20 inches (30.5 mm). This selector switch head is rated IP66/IP67/IP69/IP69K for high protection, withstands up to 500,000 mechanical cycles, and resists high-pressure washers up to 7,000,000 Pa. Suitable for demanding industrial environments with operating temperatures from -40 to 158 °F.
Schneider Electric ZB4FK1833 Selector Switch Head Specifications:
- Mounting Diameter: 1.20 in (30.5 mm)
- Head Type: Built-in-flush
- Color: Green
- Lighting: Integral LED
- Shape: Round
- Operator Profile: Green standard handle
- Positions: 3 positions, +/- 45°
- Overall Width: 1.44 in (36.6 mm)
- Overall Height: 1.44 in (36.6 mm)
- Overall Depth: 1.85 in (47 mm)
- Weight: 0.17 lb (0.078 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Mechanical Durability: 500,000 cycles
- Protection Ratings: IP66/IP67/IP69/IP69K, Type 13, Type 12, Type 4, Type 4X UL 50E
- IK Degree: IKO6
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA, CE, JIS C8201-5-1
- Vibration Resistance: 5 gn, IEC 60068-2-6
- Shock Resistance: 30 gn for 18 ms, IEC 60068-2-27
- Operating Temperature: -40 to 158 °F (-40 to 70 °C)
- Certifications: UL Listed, CSA, CCC, EAC
- Environmental Compliance: RoHS, REACH free of SVHC, Mercury free
- Package Weight: 1 lb (0.45 kg)
Buy the Schneider Series XB4 Green Selector Switch: ZB4FK1833
Order the Schneider Series XB4 Green Selector Switch Head ZB4FK1833 online today to enhance your control panels with reliable, IP69 rated protection and vibrant green illumination. Designed for durability, it offers IP66/IP67/IP69/IP69K certifications, withstands high-pressure cleaning, and supports 500,000 cycles. Ideal for industrial automation and machinery, it features a built-in LED indicator, robust construction, and easy mounting. Secure your control solutions by purchasing this durable, environmentally compliant switch head now.
Buy Schneider Series XB4 ZB4FK1833 now and experience unmatched reliability and industrial performance in control applications.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FK1833?
You can click on the BUY or RFQ button to purchase ZB4FK1833 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FK1833?
You can download the ZB4FK1833 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FK1833?
Schneider Electric
