Schneider Electric ZB4FK1853 Industrial Selector Switch
The ZB4FK1853 is a flush mounted orange illuminated selector switch with a three-position head that returns right to center. Designed for industrial control panels, it features a round shape, built-in-flush head, and a 1.20-inch (30.5 mm) mounting diameter. The switch is rated IP66, IP67, IP69K, and conforms to IEC and UL standards, making it suitable for harsh environments. It incorporates integral LED lighting, mechanical durability of 500,000 cycles, and excellent resistance to pressure washing and vibration. Its environment ratings include -40 to 158°F. Easy to install and highly reliable for demanding applications.
Schneider Electric ZB4FK1853 Industrial Selector Switch Specifications:
- Range of product: Harmony XB4
- Device short name: ZBAF
- Head type: Built-in-flush
- Shape of signaling unit: Round
- Mounting diameter: 1.20 in (30.5 mm)
- CAD overall width: 1.44 in (36.6 mm)
- CAD overall height: 1.44 in (36.6 mm)
- CAD overall depth: 1.85 in (47 mm)
- Resistance to high pressure washer: 7000000 Pa at 55°C, 0.1m distance
- Mechanical durability: 500000 cycles
- Electrical composition: M3, M6, M10, M4 with integral LED and transformer options
- Protection rating: IP66, IP67, IP69, IP69K
- IK degree of protection: IKO6
- Standards: UL 508, IEC 60947-5-1, IEC 60947-5-4, CSA, JIS C8201, CE
- Vibration resistance: 5 gn, IEC 60068-2-6
- Shock resistance: 30 gn / 50 gn, IEC 60068-2-27
- Operating temperature: -40°F to 158°F (-40°C to 70°C)
- Warranty: 18 months
- Certifications: UL Listed, CSA, CCC, EAC
- Package weight: 1 lb (0.45 kg)
Buy the Schneider Electric Series XB4 ZB4FK1853 Selector Switch: ZB4FK1853
Order the Schneider Electric ZB4FK1853 online today to enhance your control panel with a robust, IP66/IP67/IP69K rated illuminated selector switch. Featuring a round shape, built-in-flush head, and three positions with right to center return, this durable switch is designed for demanding industrial settings. Its integral LED lighting ensures visibility, while its resistance to pressure washing, vibration, and extreme temperatures guarantees long-lasting performance. With an 18-month warranty, seamless installation, and compliance with global standards, it delivers efficiency and reliability for your automation needs.
Buy Schneider Electric ZB4FK1853 now and experience unmatched reliability and performance in harsh industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FK1853?
You can click on the BUY or RFQ button to purchase ZB4FK1853 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FK1853?
You can download the ZB4FK1853 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FK1853?
Schneider Electric
