Schneider Electric ZB4FK1883 Selector Switch
The ZB4FK1883 is a flush-mounted, yellow illuminated selector switch designed for industrial control panels. Featuring a built-in-flush head with three positions (+/- 45°), it offers rotary operation with high durability for frequent use. Compliant with IEC and UL standards, it boasts an IP66/IP67/IP69/IP69K protection rating, making it resistant to dust, water, and high-pressure washing. Its robust construction, resistance to vibrations and shocks, and environment tolerance ensure reliable performance in harsh conditions, supporting automation and machinery control applications.
Schneider Electric ZB4FK1883 Selector Switch Specifications:
- Mounting Diameter: 1.20 in (30.5 mm)
- Shape: Round
- Head Type: Built-in-flush
- Operator Profile: Yellow standard handle
- Operator Positions: 3 positions +/- 45°
- Overall Width: 1.44 in (36.6 mm)
- Overall Height: 1.44 in (36.6 mm)
- Overall Depth: 1.85 in (47 mm)
- Net Weight: 0.17 lb (0.078 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C, 0.1m distance
- Mechanical Durability: 500,000 cycles
- Electrical Composition Code: M3, M6, M10, M4 with integral LED
- Protection Ratings: IP66, IP67, IP69, IP69K, Type 13, Type 12, Type 4, Type 4X
- IK Degree: IKO6
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA, JIS C8201-5-1, CE
- Environmental: -40°F to 158°F (-40°C to 70°C)
- Vibration Resistance: 5 gn, 10-500 Hz
- Shock Resistance: 30 gn for 18 ms
- Certifications: UL Listed, CSA, CCC, EAC
- Package Weight: 1 lb (0.45 kg)
- Warranty: 18 months
Buy the Buy Schneider Electric ZB4FK1883 Selector Switch Part Number ZB4FK1883 Online
Enhance your control panel with the Schneider Electric ZB4FK1883 selector switch, offering robust performance, IP69K protection, and high durability for demanding industrial environments. This 3-position rotary switch features a flush-mounted round design, built-in LED illumination, and exceptional resistance to shocks, vibrations, and high-pressure cleaning. Ideal for automation and machinery applications, it complies with global standards like IEC, UL, and CSA, ensuring reliable operation in harsh conditions. Purchase online today for quality and long-lasting control solutions.
Get Schneider Electric ZB4FK1883 selector switch today—built for industrial automation, high durability, and reliable control performance.
