Schneider Electric ZB4FL3 industrial pushbutton
The ZB4FL3 is a durable, non-illuminated green projecting pushbutton designed for industrial control panels. It features a round, built-in-flush head with a chromium-plated metal bezel, mounting diameter of 1.20 inches (30.5 mm), and overall dimensions of 1.44 inches (36.6 mm) in width and height with a depth of 1.30 inches (33 mm). Rated for 10 million mechanical cycles, it withstands environmental challenges with IP66/IP67/IP69 protection levels and conforming to IEC standards. Suitable for hazardous environments, it is CSA, UL listed, RoHS compliant, and designed for reliable operation in rugged industrial applications.
Schneider Electric ZB4FL3 industrial pushbutton Specifications:
- Mounting diameter: 1.20 inches (30.5 mm)
- Overall width: 1.44 inches (36.6 mm)
- Overall height: 1.44 inches (36.6 mm)
- Overall depth: 1.30 inches (33 mm)
- Head type: Built-in-flush
- Shape: Round
- Color: Green
- Material: Chromium plated metal
- Electrical composition code: C1, C2, C11, C15
- Mechanical durability: 10,000,000 cycles
- Ingress protection: IP66, IP67, IP69
- IK degree of protection: IKO6
- Standards compliance: IEC 60947-5-1, UL, CSA
- Vibration resistance: 5 gn, 10-500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms)
- Temperature range for storage and operation: -40°F to 158°F (-40°C to 70°C)
- Warranty: 18 months
- Certifications: UL Listed, CSA, RoHS compliant
- Package weight: 1 lb (0.45 kg)
Buy the Schneider Electric ZB4FL3 – Reliable Industrial Pushbutton for Control Panels
Enhance your control panel with the Schneider Electric ZB4FL3 green flush-mounted pushbutton. Constructed for rugged industrial environments, this IEC 60947-5-1 compliant, IP66/IP67/IP69 rated pushbutton ensures reliable operation with a lifespan of 10 million cycles. Its durable chromium-plated metal bezel and round head design provide a sleek, professional look. Ideal for automation systems, machinery, and safety controls, this switch offers superb environmental protection, easy installation, and maintenance, making it a perfect choice for demanding industrial settings.
Buy Schneider Electric ZB4FL3 now and experience unmatched durability and precise control for industrial applications.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FL3?
You can click on the BUY or RFQ button to purchase ZB4FL3 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FL3?
You can download the ZB4FL3 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FL3?
Schneider Electric
