Schneider Electric ZB4FL4 Red Pushbutton Switch
The ZB4FL4 is a round, flush-mounted, red projecting pushbutton with a built-in head designed for industrial control panels. It features a spring return operator profile with a chromium-plated metal bezel, offering excellent durability with a mechanical lifespan of 10 million cycles. Suitable for environments requiring high IP66/IP67/IP69 protection, it complies with IEC, UL, CSA, and other standards. The device supports multiple electrical configurations, with a mounting diameter of 30.5 mm and overall dimensions of 36.6 mm width and height. It’s ideal for automation systems needing reliable, non-illuminated push buttons with robust environmental resistance.
Schneider Electric ZB4FL4 Red Pushbutton Switch Specifications:
- Mounting diameter: 30.5 mm (1.20 in)
- Overall width: 36.6 mm (1.44 in)
- Overall height: 36.6 mm (1.44 in)
- Overall depth: 33 mm (1.30 in)
- Bezel material: Chromium plated metal
- Head type: Built-in-flush, round shape
- Operator profile: Red projecting, unmarked
- Mechanical durability: 10,000,000 cycles
- Environmental ratings: IP66, IP67, IP69K, Type 13, 12, 4, 4X UL
- Ambient temperature: -40°F to 158°F (-40°C to 70°C)
- Overvoltage category: IEC 60536 Class
- Protection: IK06, compliant with IEC 50102
- Standards: CSA C22.2 No 14, EN/IEC 60947-5-1, UL 508, CE, JIS C8201-5-1
- Certifications: UL Listed, CSA, EAC
- Vibration resistance: 5 gn at 10-500 Hz
- Shock resistance: 30 gn for 18 ms; 50 gn for 11 ms
- Package weight: 1 lb (0.45 kg)
Buy the Schneider Series XB4 ZB4FL4: Durable Red Pushbutton
Purchase the Schneider Series XB4 ZB4FL4 red flush-mounted pushbutton online today and enjoy a high-quality, durable control component. Designed for industrial control panels, this device offers excellent environmental resistance with IP66/IP67/IP69 ratings, built-in-flush round shape, and a long mechanical lifespan of 10 million cycles. Its chromium-plated metal bezel ensures robustness, while its versatile electrical configurations support various automation applications. Ideal for safety-critical environments, this pushbutton combines reliability, protection, and performance, making it a smart choice for engineers and technicians seeking top-tier industrial control solutions.
Buy Schneider Series XB4 ZB4FL4 red flush-mounted pushbutton now and experience unmatched reliability and performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FL4?
You can click on the BUY or RFQ button to purchase ZB4FL4 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FL4?
You can download the ZB4FL4 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FL4?
Schneider Electric
