Schneider Electric ZB4FL434 Industrial Push Button Head
The ZB4FL434 is a robust, non-illuminated flush-mounted push button head made of chromium plated metal, designed for industrial control panels. It features a round shape with a red projecting operator marked STOP, spring return operation, and a mounting diameter of 1.20 inches. This device offers high durability with a mechanical life of 10 million cycles and is rated IP66, IP67, IP69K, and UL Type 4/4X. Its environmental resistance ensures reliable performance in demanding industrial environments, conforming to IEC and UL standards for safety and durability.
Schneider Electric ZB4FL434 Industrial Push Button Head Specifications:
- Material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Shape: Round
- Head type: Built-in-flush
- Operator profile: Red projecting, STOP (white)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 1.30 in (33 mm)
- Mechanical durability: 10,000,000 cycles
- Protection ratings: IP66, IP67, IP69K, UL Type 12, 13, 4, 4X
- Vibration resistance: 5 gn at 10-500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms)
- Standards: IEC 60947, UL 508, CSA, CE, JIS C8201
- Certifications: UL Listed, CSA, CE, EAC
- Environmental ratings: Operating temperature -40 to 158 °F (-40 to 70 °C)
Buy the Schneider Electric ZB4FL434 – Reliable Industrial Push Button for Control Panels
Enhance your industrial control systems with the high-durability Schneider Electric push button head. Constructed from chromium-plated metal, it features a round design with a striking red STOP marking, ensuring clear visibility. Rated IP66/IP67/IP69K and UL Type 4/4X, it withstands harsh environments, vibration, and shocks. The device’s spring return operator ensures reliable operation through extensive cycles, making it ideal for demanding applications. Easy to install and maintain, this push button guarantees safety, durability, and performance in your control panels.
Get Schneider Electric ZB4FL434 today—built for precision, durability, and seamless control panel integration.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FL434?
You can click on the BUY or RFQ button to purchase ZB4FL434 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FL434?
You can download the ZB4FL434 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FL434?
Schneider Electric
