Schneider Electric ZB4FL5 industrial pushbutton
The flush mounted orange projecting pushbutton ZB4FL5 belongs to the Harmony XB4 series. Designed with a built-in-flush head and round shape, it features a chromium-plated metal bezel and operates with a spring return operator profile. Suitable for demanding environments, it offers IP66, IP67, IP69 protection ratings, and IK06 impact resistance. With a mounting diameter of 30.5 mm and dimensions of 36.6 mm width and height, it ensures mechanical durability up to 10 million cycles. Compliant with IEC, UL, CSA standards, it handles ambient temperatures from -40°C to 70°C and is suitable for various industrial applications.
Schneider Electric ZB4FL5 industrial pushbutton Specifications:
- Mounting Diameter: 30.5 mm
- Overall Width: 36.6 mm
- Overall Height: 36.6 mm
- Overall Depth: 33 mm
- Head Type: Built-in-flush
- Shape: Round
- Operator Profile: Spring return
- Mechanical Durability: 10,000,000 cycles
- Protection Ratings: IP66, IP67, IP69K, Type 13, Type 12, Type 4, Type 4X
- Impact Resistance: IK06
- Ambient Temperature Range: -40°C to 70°C
- Vibration Resistance: 5 gn 10-500 Hz
- Shock Resistance: 30 gn (18 ms), 50 gn (11 ms)
- Certifications: UL Listed, CSA, EAC
- Standards: IEC 60947-5-1, IEC 60947-5-4, UL 508, IEC 60947-1, JIS C8201-5-1, CE
- Package Weight: 1 lb (0.45 kg)
- Package Dimensions (H×W×L): 4.3×5.2×6.5 cm
- Warranty: 18 months
- Environmental Compliance: RoHS, REACH, China RoHS, Green Premium
Buy the Buy Schneider Electric Pushbutton Part Number ZB4FL5 Online
Purchase the Schneider Electric ZB4FL5 orange flush mount pushbutton online today to ensure reliable operation in your automation systems. Featuring a durable design with extensive IP ratings and a spring return operator, this pushbutton withstands harsh environments and millions of cycles. Its compact size with 30.5 mm mounting diameter makes it suitable for various control panels. Enjoy quick and hassle-free online ordering, ensuring your project stays on schedule with a trusted component that meets all relevant safety and environmental standards.
Buy Schneider Electric ZB4FL5 now and experience unmatched reliability and performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FL5?
You can click on the BUY or RFQ button to purchase ZB4FL5 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FL5?
You can download the ZB4FL5 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FL5?
Schneider Electric
