Schneider Electric ZB4FV013 Pilot Light Head
The ZB4FV013 is a flush-mounted white pilot light head designed for integral LED signaling applications. It features a round shape with a white plain lens, compatibility with integral LED devices, and a durable chromium-plated metal bezel. This pilot light head offers high resistance to pressure washing, with an IP66, IP67, IP69, and IP69K rating, and withstands harsh environments with an operating temperature range of -40°C to +70°C. It is suitable for industrial control systems, automation, and signaling tasks, ensuring reliable performance and easy installation with a mounting diameter of 30.5 mm. The unit weighs 0.13 lbs (0.058 kg) and meets relevant standards for safety and quality.
Schneider Electric ZB4FV013 Pilot Light Head Specifications:
- Shape of signaling unit: Round
- Color: White
- Lens: Plain
- Bezel material: Chrome plated metal
- Mounting diameter: 30.5 mm
- Overall width: 36.6 mm
- Overall height: 36.6 mm
- Overall depth: 31 mm
- Weight: 0.058 kg (0.13 lbs)
- Pressure washer resistance: 7000000 Pa at 55 °C
- Electrical composition code: P4, P2
- Protection ratings: IP66, IP67, IP69, IP69K, Type 13, 12, 4, 4X UL
- Vibration resistance: 5 gn 10–500 Hz
- Shock resistance: 30 g 18 ms, 50 g 11 ms
- Operating temperature: -40°C to +70°C
- Standards: IEC 60536, IEC 60529, IEC 50102, UL 508, CSA C22.2 No 14, JIS C8201-5-1, CE
- Certifications: UL Listed, CSA, EAC
- Warranty: 18 months
Buy the Buy Schneider Electric ZB4FV013 Part Number ZB4FV013 Online
Purchase the Schneider Electric ZB4FV013 pilot light head online today to ensure high-quality industrial signaling. This robust, flush-mounted LED indicator features durable chrome-plated metal bezel and offers an IP66/IP67/IP69K rating for superior environmental resistance. Its round design with a white plain lens makes it ideal for automation and control applications needing clear visual indication in harsh conditions. With an 18-month warranty, fast shipping, and compatibility with various standards, it’s the perfect choice for reliable process safety and operational efficiency.
Order your Schneider Electric ZB4FV013 pilot light head today and enhance your control system with reliable, corrosion-resistant LED signaling.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FV013?
You can click on the BUY or RFQ button to purchase ZB4FV013 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FV013?
You can download the ZB4FV013 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FV013?
Schneider Electric
