Schneider Electric ZB4FV033 Pilot Light
The ZB4FV033 is a flush-mounted green pilot light head compatible with integral LED systems, designed for industrial automation. It features a round, built-in-flush head with a chromium-plated metal bezel and a diameter of 1.20 inches (30.5 mm). This robust indicator offers IP66/IP67/IP69/IP69K protection, suitable for harsh environments. It withstands high-pressure washers, vibration, and shocks, and operates across a wide temperature range of -40°C to 70°C. Certified by UL, CSA, and CE, it ensures reliability for safety and signaling applications in manufacturing and control systems.
Schneider Electric ZB4FV033 Pilot Light Specifications:
- Material: Chromium plated metal bezel
- Mounting diameter: 1.20 in (30.5 mm)
- Shape: Round, Built-in-flush head
- Color: Green
- Electrical composition code: P4 front mounting integral LED, P2 front mounting integral LED and transformer
- Protection rating: IP66, IP67, IP69, IP69K, Type 13, 12, 4, 4X UL 50E
- IK degree of protection: IKO6
- Operating temperature: -40°C to 70°C (~40°F to 158°F)
- Resistance to high pressure washer: 7000000 Pa at 55°C, distance 0.1m
- Vibration resistance: 5 gn 10-500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms), 25 gn 6 ms shocks on each axis
- Weight: 0.13 lb (0.058 kg)
- Standards: IEC 60947-5-4, IEC 60947-5-1, UL 508, CSA C22.2 No 14, IEC 60068-2-6, IEC 60068-2-27, JIS C8201-5-1
- Certifications: UL Listed, CSA, CE, EAC
- Environmental: RoHS compliant, SVHC free, Toxic heavy metal free, Mercury free
- Package weight: 1 lb (0.45 kg), Dimensions: 2.17 in x 2.05 in x 1.73 in
Buy the Buy Schneider Electric ZB4FV033 Part Number ZB4FV033 Online
Acquire the Schneider Electric ZB4FV033 green LED pilot light head online today. Designed for durability in tough industrial settings, this IP66/IP67/IP69K rated round indicator features a flush mount, corrosion-resistant chromium bezel, and operates across a wide temperature range. Its high-pressure washer resistance and shock durability make it ideal for manufacturing, automation, and safety applications. Certified by UL, CSA, and CE, it guarantees compliance and reliable signaling, ensuring your machinery and control panels are distinctly visible and operational.
Order your Schneider Series ZB4FV033 green pilot light today and ensure reliable signaling in your industrial control systems.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FV033?
You can click on the BUY or RFQ button to purchase ZB4FV033 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FV033?
You can download the ZB4FV033 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FV033?
Schneider Electric
