Schneider Electric ZB4FV043 Pilot Light
The ZB4FV043 is a flush mounted red pilot light head designed for integral LED applications in industrial control systems. With a round shape, it features a chromium-plated metal bezel and a built-in, flush head type for seamless installation. Suitable for environments requiring high protection levels, it is IP66, IP67, IP69, and IP69K rated, conforming to IEC 60529 standards. The device operates within an ambient temperature range of -40°F to 158°F and is resistant to high-pressure washing, vibration, and shock. It integrates electrical composition codes for front mounting with LED technology, ensuring durability and reliability in demanding industrial settings. Certified UL Listed, CSA, and compliant with international standards, it is ideal for signaling and process indications in automation and control systems.
Schneider Electric ZB4FV043 Pilot Light Specifications:
- Bezel Material: Chromium plated metal
- Mounting Diameter: 1.20 in (30.5 mm)
- Overall Width: 1.44 in (36.6 mm)
- Overall Height: 1.44 in (36.6 mm)
- Overall Depth: 4.22 in (31 mm)
- Net Weight: 0.13 Ib (0.058 kg)
- Protection Rating: IP66, IP67, IP69, IP69K conforming to IEC 60529, Type 13 and 12 UL 50E, Type 4 and 4X UL 50E
- IK Degree of Protection: IKO6 IEC 50102
- Vibration Resistance: 5 gn 10...500 Hz IEC 60068-2-6
- Shock Resistance: 30 gn 18 ms IEC 60068-2-27
- Temperature Range (Operation & Storage): -40°F to 158°F (-40°C to 70°C)
- Environmental Certifications: UL Listed, CSA, CE, EAC
- Material: Durable metal with integral LED and plain lens operator
- Electrical Compatibility: P4 front mounting for LED, P2 for LED and transformer
- Resistance to high-pressure washer: 7,000,000 Pa at 55°C from 0.1m distance
Buy the Buy Schneider Electric ZB4FV043 Control Light Part Number ZB4FV043 Online
Enhance your control panels with the Schneider Electric Pilot Light. Featuring a durable metal bezel, high IP ratings, and reliable LED technology, this flush mounted red indicator provides clear signaling in demanding industrial environments. Ideal for automation, machinery, and process control applications, it offers excellent vibration and shock resistance. Easy to install and designed for long-term durability, order online today for fast delivery and dependable operation that meets international safety standards for industrial control systems.
Order your Schneider Electric Series ZB4FV043 red pilot light today and enhance your industrial signaling solutions with reliable LED indication.
