Schneider Electric ZB4FV053 Industrial Pilot Light
The ZB4FV053 is a flush-mounted orange pilot light head designed for integral LED systems, suitable for industrial signaling. It features a round shape with a chromium-plated metal bezel, measuring 1.20 inches (30.5 mm) in mounting diameter, and overall dimensions of 1.44 inches (36.6 mm) in width and height, with a depth of 4.22 inches (31 mm). The device is IP66, IP67, IP69, IP69K protected, and resistant to high-pressure washers up to 7,000,000 Pa at 55°C. It complies with IEC standards, UL, CSA certifications, and environmental regulations, making it ideal for demanding industrial applications.
Schneider Electric ZB4FV053 Industrial Pilot Light Specifications:
- Shape: Round
- Color: Orange
- Bezel material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 4.22 in (31 mm)
- Net weight: 0.13 lb (0.058 kg)
- Protection rating: IP66, IP67, IP69, IP69K conforming to IEC 60529 and IEC 60553
- Vibration resistance: 5 gn, 10...500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms), 25 gn 6 ms, IEC 60068-2-27
- Resistance to high-pressure washer: 7,000,000 Pa at 55°C, 0.1m distance
- Ambient temperature for storage and operation: -40°C to +70°C
- Standards: IEC 60947-5-4, IEC 60947-5-1, UL 508, CSA C22.2 No 14, CE, JIS C8201-5-1, JIS C8201-1
- Certifications: UL Listed, CSA, EAC, CCC
- Environmental compliance: RoHS, China RoHS, REACH
- Warranty: 18 months
Buy the Schneider Electric Series Harmony XB4 Pilot Light Head: ZB4FV053
Purchase the Schneider Electric ZB4FV053 industrial pilot light online today to enhance your automation and signaling systems. This high-quality, IP69-rated round orange LED head features durable chromium plating, resistant to high-pressure washers, vibration, and shock. With IEC standards compliance and environmental certifications, it guarantees reliability in demanding environments. Install this built-in flush-mounted signal indicator for clear, effective signaling. Enjoy fast delivery and secure online payment options to meet your industrial signaling needs efficiently.
Buy Schneider Electric ZB4FV053 now and experience unmatched reliability and performance with high-pressure wash resistance and IP69 protection for industrial signaling.
