Schneider Electric ZB4FV083 industrial pilot light
The ZB4FV083 is a yellow pilot light with a plain lens designed for flush mounting, offering robust IP66/67/69 protection and IEC standards compliance. Featuring an integral LED with a built-in flush head, it is suitable for industrial signaling applications. Its durable chromed metal bezel, with a mounting diameter of 30.5 mm, ensures reliable operation in harsh environments, with resistance to high-pressure washing, vibrations, and shocks. Approved under UL, CSA, and IEC standards, this indicator fits seamlessly into control panels and automation systems, providing clear visual signaling with high durability.
Schneider Electric ZB4FV083 industrial pilot light Specifications:
- Mounting diameter: 30.5 mm
- Shape: Round
- Head type: Built-in-flush
- Lens color: Yellow
- Overall width: 36.6 mm
- Overall height: 36.6 mm
- Overall depth: 31 mm
- Net weight: 0.058 kg
- Protection: IP66, IP67, IP69, IP69K (IEC 60529), Type 13, 12, 4, 4X UL 50E
- Vibration resistance: 5 gn 10...500 Hz IEC 60068-2-6
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms), IEC 60068-2-27
- Resistance to high-pressure washer: 7,000,000 Pa at 55°C
- Environmental ratings: -40°C to +70°C, IEC standards
- Standards: ENAEC 60947-5-4, UL 508, CSA C22.2 No 14
Buy the Schneider Series Harmony XB4 Pilot Light: ZB4FV083
Order the Schneider Electric ZB4FV083 yellow pilot light with plain lens online today and enhance your control panel with a reliable, durable, and IEC-compliant indicator. Its IP66/IP67/IP69 ratings ensure superb environmental protection, suitable for harsh industrial environments. Featuring an integral LED, built-in flush head, and high-impact resistance, this pilot light is ideal for signaling and automation systems. Easy to install, UL and CSA certified, and compliant with RoHS and REACH regulations, making it an excellent choice for modern industrial applications.
Buy Schneider ZB4FV083 now and experience unmatched reliability and high durability in industrial signaling solutions.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FV083?
You can click on the BUY or RFQ button to purchase ZB4FV083 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FV083?
You can download the ZB4FV083 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FV083?
Schneider Electric
