Schneider Electric ZB4FW133 Illuminated Pushbutton
The ZB4FW133 is a flush-mounted, green projecting illuminated pushbutton head with an integral LED, suitable for industrial control panels. It features a round shape, a built-in-flush head type, and a chromium-plated metal bezel. This durable device withstands high-pressure cleaning up to 7,000,000 Pa, with mechanical longevity of 10 million cycles. It conforms to IP66, IP67, IP69, and IP69K ratings, making it ideal for harsh environments. Certified by UL, CSA, and compliant with IEC standards, this pushbutton offers reliable operation in demanding industrial settings with environmental and electrical robustness.
Schneider Electric ZB4FW133 Illuminated Pushbutton Specifications:
- Mounting Diameter: 30.5 mm (1.20 in)
- Head Shape: Round, built-in-flush
- Bezel Material: Chromium plated metal
- Overall Width and Height: 36.6 mm (1.44 in)
- Overall Depth: 35 mm (4.38 in)
- Weight: 0.06 kg (10.13 lb)
- Ingress Protection: IP66, IP67, IP69, IP69K, Type 13, Type 12, Type 4, Type 4X
- Vibration Resistance: 5 gn, 10-500 Hz
- Shock Resistance: 30 gn (18 ms), 50 gn (11 ms)
- Mechanical Durability: 10 million cycles
- Electrical Compatibility: M1, M26, M6, M10 (integral LED options)
- Ambient Temperature: -40°C to +70°C
- Certifications: UL Listed, CSA, CE, EAC
- Environmental Resistance: High pressure washer resistant to 7,000,000 Pa at 55°C
- Material: Chromium plated metal bezel, plastic operator with plain lens
- Standards: EN/IEC 60947-5-1, 60947-5-4, UL 508, JIS C8201-5-1
- Package Weight: 0.45 kg (1 lb), Package Dimensions: 4.3 cm x 5.2 cm x 5.5 cm
Buy the Schneider Electric ZB4FW133 – Reliable Pushbutton for Industrial Applications
Enhance your automation setup with the Schneider ZB4FW133 illuminated pushbutton, featuring a robust design, integral LED, and high IP ratings. Ideal for demanding industrial environments, this durable, stainless steel bezel pushbutton ensures long-lasting performance. Easy to mount with a 30.5 mm diameter, it withstands high-pressure cleaning, vibration, and shock. Certified by UL, CSA, and CE, it offers reliable operation in harsh conditions. Purchase online today for fast delivery and trusted quality that enhances control system reliability across manufacturing, automation, and control applications.
Order your Schneider Series ZB4FW133 pushbutton today and give your control panels the durable quality they deserve, suitable for rugged industrial environments.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FW133?
You can click on the BUY or RFQ button to purchase ZB4FW133 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FW133?
You can download the ZB4FW133 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FW133?
Schneider Electric
