Schneider Electric ZB4FW143 Illuminated Pushbutton
The ZB4FW143 is a flush-mounted, red projecting illuminated pushbutton head designed for industrial control and automation applications. It features a round shape with a plain lens, built-in-flush head, and spring return operator profile, providing high durability of up to 10 million cycles. Manufactured from chromium-plated metal, it offers robust environmental protection with an IP66/IP67/IP69/IP69K rating, suitable for harsh environments. The device supports multiple electrical configurations with integral LEDs, complying with IEC standards and certified UL, CSA, CCC, and EAC. Suitable for control panels and machinery, it withstands high-pressure washing, shock, and vibration, making it ideal for demanding industrial settings.
Schneider Electric ZB4FW143 Illuminated Pushbutton Specifications:
- Shape: Round
- Head type: Built-in-flush
- Color: Red projecting, unmarked
- Lens: Plain
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 4.38 in (35 mm)
- Weight: 10.13 Ib (0.06 kg)
- Protection rating: IP66, IP67, IP69, IP69K, Type 13 UL 50E, Type 12 UL 50E, Type 4 UL 50 E, Type 4X UL 50 E
- Vibration resistance: 5 gn 10...500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms), 25 gn 6 ms
- Mechanical durability: 10 million cycles
- Electrical codes: M1, M26, M6, M10 with integral LED
- Ambient temperature: -40°C to +70°C
- Compliance: IEC 60947-5-1, IEC 60947-5-4, UL 508, CSA, CE
- Certifications: UL Listed, CSA, CCC, EAC
Buy the Buy Schneider Electric ZB4FW143 Part Number ZB4FW143 Online
Order the Schneider Electric illuminated pushbutton ZB4FW143 online today for your industrial control panels. Featuring a durable, flush-mounted red LED head, it offers IP66/IP67/IP69 protection and withstands harsh environments, including high-pressure washing, shock, and vibration. With multiple electrical configurations supporting integral LEDs, it is ideal for demanding industrial applications. Its robust construction ensures a long operational life, up to 10 million cycles, making it perfect for manufacturing, machinery, and automation systems. Easily install this reliable control component today for enhanced operational safety and efficiency.
Get Schneider Electric ZB4FW143 today—designed for industrial control with high environmental resistance and long-lasting durability.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FW143?
You can click on the BUY or RFQ button to purchase ZB4FW143 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FW143?
You can download the ZB4FW143 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FW143?
Schneider Electric
