Schneider Electric ZB4FW153 Illuminated Pushbutton
The ZB4FW153 is a round, flush-mounted orange projecting illuminated pushbutton head with an integral LED, designed for industrial control applications. It features a spring return operator profile, a 30.5 mm mounting diameter, and conforms to IP66, IP67, IP69/IP69K protection ratings. Made of chromium-plated metal, it withstands harsh environments with high pressure washer resistance and mechanical durability of 10 million cycles. Suitable for various safety and automation systems, it offers reliable operation in demanding industrial settings, compliant with IEC, UL, CSA standards, ensuring durability and safety.
Schneider Electric ZB4FW153 Illuminated Pushbutton Specifications:
- Mounting Diameter: 30.5 mm (1.20 inches)
- Head Shape: Round, flush-mounted
- Operator Profile: Spring return, orange projecting, plain lens
- Protection Ratings: IP66, IP67, IP69, IP69K, Type 12, 13 UL 50E, Type 4, 4X UL 50E
- Material: Chromium-plated metal
- Resistance to High Pressure Washer: 7,000,000 Pa at 55°C, 0.1 m distance
- Mechanical Durability: 10,000,000 cycles
- Ambient Operating & Storage Temperature: -40°F to 158°F (-40°C to 70°C)
- Vibration Resistance: 5 gn, 10-500 Hz
- Shock Resistance: 30 gn for 18 ms, 50 gn for 11 ms
- Electrical Compatibility: M1, M26, M6, M10 with integral LED options
- Certifications: UL Listed, CSA, CE, EAC
- Standard Compliance: IEC 60947-5-1, IEC 60947-5-4, UL 508
- Package Weight: 0.45 kg (1 lb)
Buy the Schneider Electric Series Harmony XB4 Pushbutton: ZB4FW153
Purchase the Schneider Electric ZB4FW153 illuminated pushbutton today for reliable, durable operation in industrial environments. Equipped with a built-in LED and designed for flush mounting, it features excellent protection ratings including IP66, IP67, and IP69K, making it ideal for harsh conditions. Its chromium-plated metal construction ensures longevity, withstanding high pressure washing and millions of cycles. The ergonomic design provides ease of use, conforming to international standards like IEC and UL, delivering safety, durability, and performance in automation solutions.
Get Schneider Electric ZB4FW153 today—built for precision and long-lasting durability in industrial control systems.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FW153?
You can click on the BUY or RFQ button to purchase ZB4FW153 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FW153?
You can download the ZB4FW153 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FW153?
Schneider Electric
