Schneider Electric ZB4FW163 Illuminated Pushbutton
The blue projecting illuminated pushbutton head ZB4FW163 is a flush-mounted, round operator suitable for industrial control panels. Designed with a chromium-plated metal bezel, it features a spring return mechanism, integral LED indicator, and compatibility with various electrical configurations. With a mounting diameter of 1.20 inches (30.5 mm), it offers high durability, IP66/IP67/IP69/IP69K protection ratings, and resistance to high-pressure washing, shocks, and vibrations. The device supports multiple standards, including IEC 60947-5-1, UL 508, and CSA, ensuring reliable operation in harsh environments. Ideal for automation and control applications, it is certified UL Listed, CSA, CCC, and EAC, and is suitable for outdoor or tough industrial settings.
Schneider Electric ZB4FW163 Illuminated Pushbutton Specifications:
- Head type: Built-in-flush, round shape
- Bezel material: Chromium plated metal
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 4.38 in (35 mm)
- Net weight: 10.13 Ib (0.06 kg)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C, 0.1m distance
- Mechanical durability: 10 million cycles
- Ingress Protection: IP66, IP67, IP69, IP69K conforming to IEC 60529
- Environmental ratings: -40°F to 158°F (-40°C to 70°C)
- Compliance standards: IEC 60947-5-1, UL 508, CSA
- Vibration resistance: 5 gn 10...500 Hz
- Shock resistance: 30 gn (18 ms), 50 gn (11 ms)
- Certifications: UL Listed, CSA, CCC, EAC
- Degree of protection: IK06
Buy the Schneider Electric ZB4FW163 – Reliable Illuminated Pushbutton for Industrial Applications
Discover the reliable Schneider Electric ZB4FW163 illuminated pushbutton, perfect for industrial control panels and automation systems. Featuring a robust, chrome-plated bezel and a round, flush-mounted design, it offers IP69K protection, high shock and vibration resistance, and multiple certifications including UL and CSA. Designed for demanding environments, this device ensures prolonged durability with up to 10 million cycles. Easy to install with a diameter of 1.20 inches, it enhances operational safety and visual signaling in manufacturing plants, outdoor setups, and automation control panels. Purchase online for quick delivery and consistent performance.
Get Schneider Electric ZB4FW163 today—built for precision, durability, and optimal control performance in tough industrial environments.
