Schneider Electric ZB4FW333 Illuminated Pushbutton Head
The ZB4FW333 is a green, flush-mounted, illuminated pushbutton head designed for industrial control panels. It features a round shape with a built-in-flush head, integral LED lighting, and a chromium plated metal bezel. With a mounting diameter of 30.5 mm, it offers high durability of 10 million cycles and excellent resistance to high-pressure washing up to 7,000,000 Pa at 55°C. The device conforms to IP66, IP67, IP69, and IP69K standards, ensuring protection in harsh environments. Suitable for various automation applications, it provides reliable operation and easy integration.
Schneider Electric ZB4FW333 Illuminated Pushbutton Head Specifications:
- Shape of signaling unit: Round head
- Head type: Built-in-flush
- Mounting diameter: 30.5 mm (1.20 in)
- Overall width: 36.6 mm (1.44 in)
- Overall height: 36.6 mm (1.44 in)
- Overall depth: 31 mm (4.22 in)
- Net weight: 0.06 kg (0.13 lb)
- Resistance to high pressure washer: 7,000,000 Pa at 55°C
- Mechanical durability: 10,000,000 cycles
- Electrical composition code: M1, M26, M6, M10
- Protection rating: IP66/IP67/IP69/IP69K
- Vibration resistance: 5 gn, 10-500 Hz
- Shock resistance: 30 gn for 18 ms, 50 gn for 11 ms
- Certification: UL Listed, CSA, CCC, EAC
- Operating temperature: -40°C to +70°C
- Environmental compliance: REACh, RoHS, China RoHS
Buy the Schneider Series XB4 ZB4FW333: Green Illuminated Pushbutton Head
Order the Schneider ZB4FW333 green illuminated pushbutton head online today to enhance your control panel with durable, high-quality, IP69-rated switching components. Perfect for demanding industrial environments, this built-in-flush switch provides reliable operation with integrated LED lighting, excellent resistance to water, dust, and mechanical wear. Its robust construction ensures long-lasting performance over millions of cycles, making it ideal for automation, machinery, and control systems. Purchase now for quick delivery and seamless integration into your industrial control solutions.
Get Schneider ZB4FW333 today—built for high durability, IP69 protection, and reliable industrial control performance.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FW333?
You can click on the BUY or RFQ button to purchase ZB4FW333 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FW333?
You can download the ZB4FW333 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FW333?
Schneider Electric
