Schneider Electric ZB4FW343 Illuminated Pushbutton
The ZB4FW343 is a high-durability, flush-mounted illuminated pushbutton head designed for industrial control panels. Made with chromium plated metal, it features a round shape with a red flush unmarked operator, suitable for environments requiring IP66/IP67/IP69 protection, and withstands high-pressure washing and mechanical cycles. It integrates an LED for visual signaling, available in various electrical configurations, and is engineered for high resistance to vibrations, shocks, and temperature extremes, making it ideal for automation and machinery control applications. It complies with international safety and quality standards, ensuring reliable performance in demanding conditions.
Schneider Electric ZB4FW343 Illuminated Pushbutton Specifications:
- Shape of signaling unit: Round
- Head type: Built-in-flush
- Mounting diameter: 1.20 in (30.5 mm)
- Overall width: 1.44 in (36.6 mm)
- Overall height: 1.44 in (36.6 mm)
- Overall depth: 4.22 in (31 mm)
- Net weight: 10.13 lb (0.06 kg)
- Bezel material: Chromium plated metal
- Protection ratings: IP66, IP67, IP69, IP69K conforming to IEC 60529
- Vibration resistance: 5 gn 10...500 Hz, IEC 60068-2-6
- Shock resistance: 30 gn (18 ms), IEC 60068-2-27
- Mechanical durability: 10,000,000 cycles
- Environmental ratings: Ambient temperature -40 to 70°C, EN/IEC 60947-5-1, UL 508
- Electrical configurations: M1, M26, M6, M10
- Protection class: Class I conforming to IEC 60536
- Certifications: UL Listed, CSA, CCC, EAC
Buy the Buy Schneider Electric ZB4FW343 Part Number ZB4FW343 Online
Purchase the Schneider Electric illuminated pushbutton ZB4FW343 online today for reliable operation in demanding industrial environments. Made from durable chromium plated metal, it features a round round head with a red flush unmarked operator enhanced with integrated LED for clear signaling. Its IP66/IP67/IP69 protection ratings ensure high resistance to water, dust, and cleaning pressures, while its mechanical durability supports millions of cycles. Suitable for automation and control panels, this switch offers proven safety, certifications, and excellent environmental resilience for long-term use and seamless integration.
Get Schneider Electric ZB4FW343 today—built for industrial robustness with high-pressure wash resistance and long-lasting LED signaling.
Frequently Asked Questions
Where can I buy Schneider Electric ZB4FW343?
You can click on the BUY or RFQ button to purchase ZB4FW343 from an authorized Schneider Electric distributor.
How do I troubleshoot issues or seek technical support for part ZB4FW343?
You can download the ZB4FW343 datasheet or visit the Schneider Electric website for support.
Who is the manufacturer of ZB4FW343?
Schneider Electric
